BLOXTECH

Shielded bollard made of stainless steel with rotationally symmetrical light distribution. For the illumination of walkways, entrances and access roads. The light of the LED is directed by a reflector onto a conical reflector. Illumination on the illuminated surface is rotationally symmetrical, broad spread and uniform. Luminaire made of stainless steel, IP65.

Recessed rectangular luminaire with ten optical elements and spot optic. Luminaire body are made of aluminium alloy, the glass-holder frame has plastic end caps. Tempered soda-lime closing glass, transparent with black screen-printing on the edge, 3mm thickness, attached to the frame with silicone. Silicone seals are placed between the glass-holder frame and the optical compartment. High-definition optic made of metallic thermoplastic, integrated into the black anti-glare screen towards the rear. Grade 304 stainless steel supporting springs. Equipped with IP68 box housing the control gear with outgoing cables for connection. The optical compartment and control gear are connected through IP68 quick-fit connectors. All external screws are made of A2 stainless steel.

Single emission submerged for outdoor application. The warm white LED light source with a medium wide flood light distribution is composed of 3 powerled LEDs. The lumaniare body is made of aisi 316l steel and features a steel finish; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP68, IK10.

Recessed ground / ceiling / wall luminaire made of aluminium housing with die-cast aluminium end caps complete with silicone seals. Installation in continuous lines of up to a max length of 10.5m for ground-recessed version. IP66,IK10. DIMENSION: 610x 87x104mm
