WE-EF

INGROUND UPLIGHT
OUTDOOR LIGHTING
EVC130-FS LED


Specification

Power
24W
Color Temperature
4000K
Light Source Type
LED
Lumen Output
3242LM
Finishing
STAINLESS STEEL
IP Rating
IP69
Color Rendering
CRI80
Driver
ON/OFF DRIVER

See more

LIGHTFORMS
SURFACE MOUNTED LIGHT
INDOOR LIGHTING
A super compact cylindrical light source with a huge range of optical options. The construction is an extruded aluminium housing packaged with either optic, reflector or LED engine - but always in the classic and clean cylindrical form. Control gear is generally always integral, but this may be restricted with certain outputs, control types and additions. But we can always work this out for you.
FORMALIGHTING
LINEAR LIGHT
INDOOR LIGHTING
Compact linear LED light is designed to be the perfect solution for optimal display lighting that preserves product longevity by emitting a low ambient temperature to prevent damage whilst providing high-quality LED lights with high efficiency and controlled temperature. No harmful infrared or ultraviolet radiation. Highly efficient LEDs with high CRI. >50% energy saving while keeping the same illumination level. Available in different lengths from 50mm to 2030mm.
XAL
LINEAR DOWNLIGHT
INDOOR LIGHTING

Rectangular recessed multi-downlight in die-cast aluminium with tool-free installation via patented ball catch system and jet black trim, suitable for 2–25 mm ceilings. Features six wide flood elements (71° beam) with chrome micro-faceted reflector for precise symmetrical distribution. Provides 3500K light, CRI ≥90, MacAdam ≤3 SDCM, and ≥85% flux after 50,000h. Passive LED cooling, IP20, PC2, 220–240V with DALI-2 converter. Includes through-wiring box (3- or 5-pole, accessory). Non-replaceable l

XAL
LINEAR DOWNLIGHT
INDOOR LIGHTING
Rectangular recessed multi-downlight made of die-cast aluminium; installation without tools in mounting set due to patented ball catch system; rectangular installation housing; for trimless installation in plasterboard ceilings; suitable for ceiling thickness of 12.5/15/20/25 mm; equipped with six medium square light elements; symmetrical light distribution with precise radiation characteristic, beam angle 32°; high quality reflector with micro-faceted, aluminum-vaporised surface; black reflector; UGR ≤ 10; VDU compatible workplace luminaire according to DIN EN 12464-1; luminance above 65° ≤ 3000 cd/m²; passive cooling of the LEDs through improved heat sink geometry; light colour 3000 K; binning initial MacAdam ≤ 3 SDCM; CRI ≥ 90; min. 90% of luminous flux after 50000 operating hours; energy-efficient high power LEDs with very good colour rendering; degree of protection IP20; PC2; incl. converter, non dimmable; through wiring connection box, 3-pole or 5-pole, available as an accessory; accessories are listed separately; light source not replaceable; control gear replaceable by an authorized professional; clank-free
