WE-EF

INGROUND UPLIGHT
OUTDOOR LIGHTING
ESC330_185-7490
IP67. IK07. Stainless steel inground section. Die-cast hood made from marine-grade aluminium alloy. Construction helps to prevent accumulation of insects, leaves and debris on lens and restricts glare to passers-by. 5CE superior corrosion protection including PCS hardware. Safety glass lens. Silicone rubber gasket. Factory-sealed termination chamber with cable gland and 0.5 m of flexible PVC-free cable. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. Removable LED boards for upgrading. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept. Luminaire installation blockout and sealable junction box included in supply.

Specification

Power
24W
Color Temperature
3000K
Light Source Type
LED
Lumen Output
2555LM
Finishing
GREY
IP Rating
IP67
Color Rendering
CRI 80
Driver
1-10V Driver

See more

FORMALIGHTING
SURFACE MOUNTED DOWNLIGHT
INDOOR LIGHTING

LED Built-in with body - High Power LED - Power LED. 3-step MacAdam

LINEALIGHT
WALL LIGHT
INDOOR LIGHTING
Multiple emission wall lights for indoor application. The warm white LED light source with a radial multidirectional emission light distribution is composed of 1 powerled LEDs. The device body is made of aluminium 6026 and features a embossed white ral 9003 finish, processed by means of powder coating. The ingress protection degree is IP20; the total weight is of 0.077 kg. The power supply driver is not provided and is to be ordered separately. The power supply cable is included and features a 0.12 m length. The device features protection class III and can be wall lights or ceilingmounted, with a 29 mm diameter hole (in plasterboard) with an outer casing, code 84915 (for concrete or masonry). Compliant with the EN 60598-1 standard and its specific provisions.
NEKO
ADJUSTABLE DOWNLIGHT
INDOOR LIGHTING

Downlight round made of die-cast aluminium with black powder-coating finish (RAL 9005); ONOFF Driver; LED 11W; measurement Ø50mm; luminaire’s weight is approximately 120g; CCT 3000K with an LED Output of 1100lm; high color rendering at an index of CRI90; after a lifetime of 50000h min. 80% of the luminous flux with energy efficient CITIZEN LED Chips; 5 years warranty; beam characteristic with 35° beam angle; lighting perfectly suitable for reading, writing as well as computer and control work ac

MEYER
INGROUND UPLIGHT
OUTDOOR LIGHTING
The Uplight S product range are luminaires with extremely shallow recess depth. This product feature ensures that the luminaries do not collide with existing infrastructure in the ground, such as electrical or water conduit. Adjustable collimator optics with various different light distributions make these products versatile tools for architectural and landscape lighting. Optimal glare control can be achieved by the use of honeycomb louvres as an accessory.
