WE-EF

INGROUND UPLIGHT
OUTDOOR LIGHTING
ESC330_185-7493

IP67. IK07. Stainless steel inground section. Die-cast hood made from marine-grade aluminium alloy. Construction helps to prevent accumulation of insects, leaves and debris on lens and restricts glare to passers-by. 5CE superior corrosion protection including PCS hardware. Safety glass lens. Silicone rubber gasket. Factory-sealed termination chamber with cable gland and 0.5 m of flexible PVC-free cable. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. Removable LED boards for upgrading. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept. Luminaire installation blockout and sealable junction box included in supply.

Specification

Power
24W
Color Temperature
4000K
Light Source Type
LED
Lumen Output
2531LM
Finishing
GREY
IP Rating
IP67
Color Rendering
CRI 80
Driver
1-10V DRIVER

See more

LINEALIGHT
CEILING LIGHT
INDOOR LIGHTING
Single emission downlights for indoor application. The warm white LED light source with a medium wide flood light distribution is composed of 6 powerled LEDs with CCT of 3000 K and a CRI 90; the source luminous flux is 1074 lm, with a 89.5 lm/W nominal luminous efficacy. The device body is made of plaster and features a white finish; the diffuser is made of ABS. The ingress protection degree is IP20; the total weight is of 0.690 kg. The power supply driver is not provided and is to be ordered separately. The total absorbed power is 12 W. The power supply cable is included and features a 0.170 m length. The device features protection class III and can be ceiling-mounted, with a 270 x 90 mm hole (in plasterboard). Compliant with the EN 60598-1 standard and its specific provisions.
COLORS
LED NEON TUBE
OUTDOOR LIGHTING

The luminaire high light transmittance, high purity silica gel material, the ingress protection degree is IP65, IK08. Unique optical light distribution structure design, 360° light output uniformly without shadows. Skin-friendly surface treatment, comfortable touch, good flexibility, and simple shape. Product application for office lighting, decorative lighting, artistic lighting, modeling contrast.

BEGA
WALL LIGHT
OUTDOOR LIGHTING
Unshielded ceiling and wall luminaire with high protection class. A luminaire made of die cast aluminium and with an impact resistant synthetic diffuser. Luminaire made of aluminium alloy, aluminium and stainless steel. IP65,IK07.
BEGA
INGROUND UPLIGHT
OUTDOOR LIGHTING

Luminaire made of stainless steel . Safety glass, white silicone gasket. Recessed location luminaire for installation in gravel, lawns, flower beds, or in compacted surfaces. Protection class IP 68 10 m , IK10
