Preview Real Lighting Products in Blox 3D Simulator Using IES Files
Products
IGUZZINI
SURFACE LINEAR LIGHT
OUTDOOR LIGHTING
BK85_3000K
Direct light luminaire, designed to use monochrome LED lamps. Ceiling- and wall-mounted. Consists of a body and supports for installation (to be ordered separately). Extruded aluminium body, with zamak die-cast end caps complete with silicone gaskets. Coated with liquid acrylic paint with a high level of weather and UV ray resistance. The top of the optical assembly is closed by a 3 mm thick transparent glass screen, fixed with silicone. Complete with multi-LED power plate in Warm White with 24V dc electronic circuit (ballast to be ordered separately); 24V smart driver allowing constant light flow emission despite variations in the input voltage (from 30V dc to 16V dc). Fitted with satin-finish polycarbonate film and optics with plastic (methacrylate) lens for 30° FLOOD lighting. All external screws used are made of A2 stainless steel. The luminaire technical characteristics conform to EN 60598-1 standards and particular requirements.
Specification
- Power
- 12W/1056mm
- Color Temperature
- 3000K
- Light Source Type
- LED
- Lumen Output
- 1080 LM
- Finishing
- GREY
- IP Rating
- IP66
- Color Rendering
- CRI 80
- Driver
- 0-10V DRIVER
