LUMASCAPE

SURFACE MOUNTED LIGHT

OUTDOOR LIGHTING

LS1012 - 24D_830_VN_ND_SL

The most compact and versatile, remote driver surface mounted luminaire in its class, featuring a light output and energy efficiency surpassing 35 W Metal Halide. Packed with features including EasyGlow™ visual comfort and CoolDrive™ thermal management technologies. Unique and flexible mounting with glare control accessories enable installation in multiple orientations including two axes of adjustment making it ideal for direct or indirect applications. Available with integrated 0-10 V dimming or as non-dimmable.

Specification

Power

24W

Color Temperature

3000K

Light Source Type

LED

Lumen Output

2450 LM

Finishing

ANODIC SILVER

IP Rating

IP66

Color Rendering

CRI 80

Driver

ON/OFF DRIVER

WE-EF

BOLLARD

OUTDOOR LIGHTING

IP66/IP67. Class I. IK10. Marine-grade, all-aluminium construction. Pole section features galvanised steel reinforcement core. 5CE superior corrosion protection including PCS hardware. RFC™ Reflection Free Contour main lens. Silicone CCG® Controlled Compression Gasket. Luminaire is factory-sealed and does not need to be opened during installation. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. CAD-optimised optics for superior illumination and glare control.

BEGA

WALL LIGHT

OUTDOOR LIGHTING

Luminaire made of aluminium alloy, aluminium and stainless steel Crystal glazing, Mounting plate with 3 fixing holes ø 5.5 mm. Angle 120° · Pitch circle ø 85 mm, 2 cable entries for through-wiring of mains supply cable ø 7-10,5 mm, max. 3 G 1.5@. Connecting terminal 2.5@ with plug connection. Earth conductor connection. LED power supply unit, 220-240 V x 0/50-60 Hz, DC 176-264 V. DC Start ≥ 198 V, Safety class I Protection class IP 44, Protected against granular foreign bodies > 1 mm and splash water, r – Safety mark, c – Conformity mark.

SPARK

INGROUND UPLIGHT

OUTDOOR LIGHTING

Inground uplight designed for full range application with great heat-dispassion, innovative waterproof construction design, passed IP68 test, and variety beam angle selected. Various anti-glare accessories option, honeycomb, bullseye or deep-set louvre for all kinds of inground application.

LUCE & LIGHT

INGROUND UPLIGHT

OUTDOOR LIGHTING

Bright 3.0 316L code: CW300009LI-4

recessed for underwater applications (suitable for use in seawater); walkover; recessed (wall, ground), max depth 10 m; Power consumption: 7W; Power supply: 24Vdc; Lumen output at source: 683 lm (3000K, 7W); Delivered lumen output: 463 lm (3000K, 34°, 7W); 1 high-intensity power LED, 3-step MacAdam, 50 000h L90 B10 (Ta 25°C); LED colour: 4000K; Optics: 45°: optical system consisting of a high-efficiency TIR lens; CRI Colour Rendering Index: 80;
