Products

PUK

FLOODLIGHT
OUTDOOR LIGHTING
RING MEGA HP_101408-4°
Floodlight for outdoor installation on a façade/wall, with 355° swivel base and allowing horizontal adjustment of +90° / -40°. Phospho-chromatised and polyester powder coated die-cast copper-free aluminium base and head, tempered safety glass, moulded silicone gaskets and o-rings, with screws in stainless steel. Swivel joint with graduated scale and mechanical aiming lock. Built-in LED driver, with 12 x CREE “XHP35” LED. IP66 rating.

Specification

Power
88W
Color Temperature
3000K
Light Source Type
LED
Lumen Output
9500LM
Finishing
GREY
IP Rating
IP66
Color Rendering
CRI 90
Driver
DALI DRIVER

See more

LIGHTFORMS
SURFACE TRACKLIGHT
INDOOR LIGHTING
Lightplane 1 H features a 25mm linear channel and delivers both direct and indirect lighting. This small channel allows for minimal linear lighting in suspended, wall and surface (direct only) applications. Driver is REMOTE.
FLOS
RECESSED DOWNLIGHT
OUTDOOR LIGHTING

Electic Ø70 Fixed downlight in Cone style. Simple and basic geometry the circle characterize this ceiling device. Functionality and versatility make the collection a go-to lighting must.  IP54

MEYER
RECESSED DOWNLIGHT
OUTDOOR LIGHTING
Housing made of corrosion‑resistant die‑cast aluminum AlSi12, polyester powder coated by high‑quality and UV‑stabilized coating process, Colour: black ral 7021, all exterior parts are stainless steel, tempered safety glass, anti‑reflective coating from 1 side, dark screenprint, silicon gasket, closure with 3 stainless steel screws, mounting bracket: 2 drilled holes Ø 7 mm, spacing 30‑40 mm, 1 centre hole Ø 17 mm, tilt range: 180°, cable gland: M20, connecting terminal: 3 pole, precise PMMA optics, integral driver (AC/DC), CRI > 80, max 2 SDCM, service life L90/B10 > 50.000 h, Beam angle (fwhm): 5°, luminous flux: 2855 lm, wattage: 46 W, delivered lumens 62 lm/W, protection type IP67, protection class I, impact resistance IK08, windage area 0,025 m², dimensions: Ø 194 mm, width 124 mm, weight 2.8 kg. The modular luminaire design makes the replacement of components possible. The product meets the demands of the applicable EU guidelines and product safety regulations and bears the CE and ENEC marks. Customized solutions and modifications are possible: Special ral, db or ncs colours as polyester powder coat, luminaires in 2700 K and other colour temperatures and versions for high ambient temperature.
FORMALIGHTING
LINEAR LIGHT
INDOOR LIGHTING
Compact linear LED light is designed to be the perfect solution for optimal display lighting that preserves product longevity by emitting a low ambient temperature to prevent damage whilst providing high-quality LED lights with high efficiency and controlled temperature. No harmful infrared or ultraviolet radiation. Highly efficient LEDs with high CRI>50% energy saving while keeping the same illumination level. Available in different lengths from 50mm to 2030mm.
