HESS

POLE LIGHT
OUTDOOR LIGHTING
17.20100.7000
Steel pole, galvanised inside and outside. Conical design. Height from ground level optionally 7000mm. Pole Ø at the bottom 168mm. Embedded base with 2 openings for cable entry, optionally with square flange plate. Separate embedded base on request. With inspection-door and C-rail for fuse-box. When equipped with ARINI light +, additional junction box for wiring of control leads. Arrangement of luminaire heads either single-sided, two-sided (180° shifted) or in 360° design. RAL Pearl-Metallic on request

Specification

Power
54W
Color Temperature
3000K
Light Source Type
LED
Lumen Output
4669LM
Finishing
GREY
IP Rating
IP65
Color Rendering
CRI 80
Driver
ON/OFF DRIVER

See more

LINEALIGHT
RECESSED DOWNLIGHT
INDOOR LIGHTING
Single emission downlights for indoor application. The warm white LED light source with a wide flood light distribution is composed of 1 arrayled LEDs. The device body is made of uv resistant polycarbonate and features a embossed black ral 9005 finish, processed by means of liquid painting; the diffuser is made of uv resistant polycarbonate. The ingress protection degree is IP44; the total weight is of 0.2 kg. The power supply driver is not provided and is to be ordered separately. The power supply cable is included and features a 0.15 m length. The device features protection class III and can be ceiling-mounted, with a 65 x 65 mm hole (in plasterboard). Compliant with the EN 60598-1 standard and its specific provisions.
FLOS
ADJUSTABLE DOWNLIGHT
INDOOR LIGHTING
Eclectic Ø90 Dim To Warm. Adjustable Downlight (40º tilt, 360º rotation). “Cone” style façade. Necessary installation pre-frames, not included (to be orderedseparately). Recessed position ofthe LED: 41º cut-off angle. IP20 water tightness (for IP54, pleaseask the dedicated accessory). Alternative options for lenses, orientation modules and style façades are available as spare parts.The ingress protection degree is IP20.
CDN LIGHTING
RECESSED DOWNLIGHT
INDOOR LIGHTING


XAL
RECESSED DOWNLIGHT
INDOOR LIGHTING

Round recessed spotlight in die-cast aluminium; 1 lamp; surface traffic white; installation without tools in mounting set due to patented ball catch system; round installation housing; with trim jet black; suitable for ceiling thickness of 2-25 mm; passive cooling of the LEDs through improved heat sink geometry; with COB (Chip on Board) technology for maximum efficiency; no appearance of multiple shadows; light colour 3500 K; ≤ 2 SDCM (initial MacAdam); CRI ≥ 90; min. 80% of luminous flux after
