LINEALIGHT

WALL LIGHT

OUTDOOR LIGHTING

90463V45

Single emission lines for outdoor application. The RGBW - 3000 K LED light source with a medium wide flood light. The device body is made of aluminium 6060 and features a anodised aluminum finish, processed by means of 20 µm anodizing; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP67; the total weight is of 3.4 kg. The total absorbed power is 37 W. The power supply cable is included and features a 0.17 m length. The device features protection class I and can be wall lights or ceilingmounted. Compliant with the EN 60598-1 standard and its specific provisions.

Specification

Power

74W

Color Temperature

RGBW 3000K

Light Source Type

LED

Lumen Output

1260LM

Finishing

ALUMINIUM

IP Rating

IP67

Color Rendering

CRI 80

Driver

ON/OFF DRIVER

XAL

LINEAR DOWNLIGHT

INDOOR LIGHTING

Rectangular recessed multi-downlight made of die-cast aluminium; installation without tools in mounting set due to patented ball catch system; rectangular installation housing; for trimless installation in plasterboard ceilings; suitable for ceiling thickness of 12.5/15/20/25 mm; equipped with six flood square light elements; symmetrical light distribution with precise radiation characteristic, beam angle 56°; high quality reflector with micro-faceted, aluminum-vaporised surface; black reflector; UGR ≤ 19; VDU compatible workplace luminaire according to DIN EN 12464-1; luminance above 65° ≤ 3000 cd/m²; passive cooling of the LEDs through improved heat sink geometry; light colour 3000 K; binning initial MacAdam ≤ 3 SDCM; CRI ≥ 90; min. 90% of luminous flux after 50000 operating hours; energy-efficient high power LEDs with very good colour rendering; degree of protection IP20; PC2; incl. converter, non dimmable; through wiring connection box, 3-pole or 5-pole, available as an accessory; accessories are listed separately; light source not replaceable; control gear replaceable by an authorized professional; clank-free

DELTALIGHT

RECESSED MAGNETIC TRACK LINEAR

INDOOR LIGHTING

Light modules can easily be positioned and repositioned, thanks to the magnetic connection between module and profile. This allows for an easy adaptation between light and room setting.Magnetic modules to be used with the SPLITLINE and SHIFTLINE profiles.Apart from personal dimming preferences, the light within the magnetic profiles can also be controlled by sensors, based on daylight or presence detection.

BEGA

BOLLARD

OUTDOOR LIGHTING

Shielded bollard with square profile and flat beam light distribution. For the illumination of paths, squares, access roads and entry areas. Luminaire made of aluminium profile, aluminium alloy, aluminium and stainless steel, IP65,IK07.

LINEALIGHT

RECESSED DOWNLIGHT

INDOOR LIGHTING

Single emission downlights for indoor application. The warm white LED light source with a medium wide flood light distribution is composed of 1 powerled LEDs. The device body is made of die-cast aluminium en ab - 46100 and features a embossed black ral 9005 finish, processed by means of powder coating; the diffuser is made of uv resistant polycarbonate. The ingress protection degree is IP44; the total weight is of 0.128 kg. The power supply driver is not provided and is to be ordered separately. The power supply cable is included and features a 0.170 m length. The device features protection class III and can be ceiling-mounted, with a 35 x 35 mm hole (in plasterboard). Compliant with the EN 60598-1 standard and its specific provisions.
