PHOS

Minilinear: "Copper Free" Aluminium extruded EN AW-6060 with high resistance against corrosion, caps in "Copper Free" Aluminium die cast housing in EN AB-44100 with high resistance against corrosion. Miniround: "Copper Free" Aluminium die cast housing in EN AB-44100 with high resistance against corrosion. Stone wash surface treatment prior to painting process. A4 grade Stainless Steel screws with 2,5-3% molybdenum content which increases the resistance against corrosion. Pre treated Silicone Gaskets (Minilinear). Painting Process : 3 Step Process 1) Surface treatment with BONDERITE. A heavy metal free chemical surface treatment containing ceramic nano particles giving a cohesive, inorganic and highly dense protective coating. 2) PRE POLYMERIZATION a process of introducing an epoxy primer with excellent characteristics to the paint which also offers very high resistance to oxidation due to its Zinc content. 3) POLYMERIZATION a process with the application of polyester powder with high resistance against UV rays and harsh weather conditions. Resistance test protection for Marine applications for 1200h. Mechanical resistance IK 09 Maximum load capacity 500 Kg. This luminaire contains built-in LED modules. In case of damage or malfunction please contact the manufacturer to receive additional instructions on how to replace and relative spare parts to order. The LED modules cannot be handled in the luminaire by the end user. This product contains a light source of energy efficiency class: E. LED modules are engineered accordingly to the existing regulations of Lumen Maintenance (LM80) and Technical Memorandum (TM21), where uniformity and quality of the light is 70,000 hours referred to L80 B10 Ta 25 ° C (50,000 hours referable to L80 B10 Ta 40°C). Lifespan of the luminaire min. 50,000 hours at 40°C. Performance Ambient temperature Tq 25°C. Operating ambient temperature range is from -20°C to +50°C. Storage temperature range from -20°C to +60°C.

Narrow LED pitch suitable for limited space installation (10mm pitch, 16mm pitch). Small section W10mm * H4mm. 2 types of wattage (3.9W, 2.5W per meter). Customized length available up to 5m per roLL.

Ginko 3.3 is an 11W outdoor projector (ceiling, wall, ground, spike) with a 24Vdc power supply, RGBW LED (447 lm source, 272 lm delivered at 4000K, 19°), and high-efficiency TIR microlenses (19°, 33°, 56°, adjustable 32°x73°). Made of corrosion-resistant aluminium or stainless steel, it has a 4mm tempered glass screen, IP66/IP69 protection, IK09 impact resistance, and IPS technology. Operating from -20°C to +45°C, it meets IEC TR 62778:2014 standards. Dimensions: Ø84x88 mm, 1350g (2500g stainles
