LUCENT

Floodlight luminaire intended for use with LED light sources. Comprising an optical compartment and base strip in die-cast aluminium and transparent tempered sodiumcalcium safety glass. Adjustable optical compartment in the horizontal plane (+90°/-50°). Graduated scale and mechanical aiming lock. Dual A2 stainless steel cable gland complete with output power supply cable. Ø116mm product with built-in DALI power supply unit.

From residential to commercial applications, the Apex Surface Mounted Downlight is an unrivalled match with its practicality and efficiency, proving a perfect fit with a plethora of power, size and accessory options. A new chip in the Apex Series improves the performance of an already superior downlight. The ingress protection degree is IP20.

Round recessed downlight made of die-cast aluminium with white powder-coating finish (RAL 9016) and white reflector; ON-OFF Driver; System Power 28W; measurements Ø110mm x 157mm; ceiling cutout of Ø100mm with a narrow mounting trim; ceiling thickness 1-25mm; rotation 355° and pivot max. 30°; CCT 3000K with a System luminous flux of 1900lm; high color rendering at an index of CRI90; after a lifetime of 50000h L80B10 min. 80% of the luminous flux with energy efficient CITIZEN LED Chips.

Recessed adjustable square downlight luminaire body made of aluminium housing with white powder coated trim finish. Black finish and honeycomb accessory available upon request.
