PIVOT MINI 1_2.5W-15°

Pivot Mini 1outdoor applications surface mounted (ceiling, wall, floor) housing made of ANTICORODAL EN AW 6082 low-copper-content aluminium alloy for excellent resistance to corrosion, made entirely on a CNC lathe. Bracket in AISI 316L stainless steel, tumble finished and painted (painted version), body made of brass, produced entirely on a CNC lathe. Bracket made of brass. Optics available for 15°, 21°, sharp 30°, 35°. IP66, IK06.

Specification

Power
2.5W
Color Temperature
3000K
Light Source Type
LED
Lumen Output
101LM
Finishing
ANTHRACITE
IP Rating
IP66
Color Rendering
CRI 90
Driver
CASAMBI

See more

IGUZZINI
SPOTLIGHT
INDOOR LIGHTING

Miniaturised adjustable spotlight with adapter for installation on 48V low voltage track. Made of die-cast aluminium with passive dissipation system. The adapter made of a thermoplastic material includes the DC/DC driver circuit with a DALI dimmable function. Integrated «power line» technology allows each spotlight mounted on the track to be regulated separately.IP20.

LINEALIGHT
WALLWASHER
OUTDOOR LIGHTING

 The power supply driver is not provided and is to be ordered separately.

The total absorbed power is 13 W. The power supply cable is included and features a 1 m length.

The device features protection class III and can be wall lights, ceiling or floor-mounted.


DALITEK
CONTROL SYSTEM
INDOOR LIGHTING

HDR-20 is one economical unit slim 30W DIN rail power supply series, adapt to be installed on TS-35/7.5 or TS-35/15 mounting rails. The body is design 35mm (2SU) in width, which allows space saving inside the cabinets. The entire adopts the full range AC input 85VAC to 264VAC (277 VAC operational) and conforms to EN61000-3-2, the form the European Union regulate for harmonic current. HDR-30 is designed with plastics housing that it can effectively prevent user from electric hazards.

IGUZZINI
SUSPENDED LINEAR LIGHT
INDOOR LIGHTING
Linear pendant direct emission luminaire with Warm White CRI90 monochrome LED lamps. General Light (High Output) luminaire with methacrylate diffusing screen available in a microtextured Opal or Smoked version. Complete with 48Vdc Mid-Power LED circuit and PWM control system (Pulse with modulation). The integrated PWM technology allows the light intensity to be adjusted by creating the effect of a dimmed light without altering the quality of the light.
