LUCE & LIGHT

Round recessed downlight made of die-cast aluminium with white powder-coating finish (RAL 9016) and white reflector; ON-OFF Driver; System Power 21W; measurements Ø110mm x 131mm; ceiling cutout of Ø100mm with a narrow mounting trim; ceiling thickness 1-25mm; rotation 355° and pivot max. 30°; CCT 3000K with a System luminous flux of 1500lm; high color rendering at an index of CRI90.

Spotlight designed to use LED lamps and a Wide Flood optic. The optical assembly and base is made of EN1706AC 46100LF aluminium alloy and subjected to a multistep, pre-treatment process, in which the main phases are degreasing, fluorozirconation (a protective surface film) and sealing (with a nano-structured silane layer). The following painting stage consists of a primer and a liquid acrylic paint, cured at 150°C, with a high level of weather and UV ray resistance. 5 mm thick tempered sodium-calcium closing glass. Double adjustability allows a 360° rotation about the vertical axis and 90° tilting relative to the horizontal plane ip66, IK07.

Protection class IP68 – for a water depth of up to 3 m. Protection class IP69 - protection against high pressure and high jet water temperatures. Entirely made of stainless steel 316Ti. Mounting foot adjustable through 180° or 90°. Operating mode: constant current. POW-LED cold white, warm white, neutral white, CC POW-LED RGB. Operating mode: constant voltage. POW-LED cold white, warm white, neutral white, CV Cable gland PG13,5, marine grade 316Ti stainless steel. Temperature-resistant silicon seal. Toughened safety glass. Supplied with 3 m of underwater cable

A series of track mounted adjustable luminaires with double pivot arms for added versatility to freely position the luminaire direction in applications where the track is hidden in ceiling troughs. Incorporating ELR’s signature modular concept design, LED modules are fully interchangeable with choices to flexibly illuminate objects ideally for showcasing and retail applications. IP40.
