IGUZZINI

RECESSED DOWNLIGHT
INDOOR LIGHTING
RL82.39

Round fixed luminaire designed to use LED lamps with C.o.B. technology. Version with rim for surface-mounting. Reflector vacuummetallised with aluminium vapours with an anti-scratch protective layer. Dissipater made of painted grey die-cast aluminium.

Specification

Power
13.3W
Color Temperature
3500K
Light Source Type
LED
Lumen Output
1157LM
Finishing
WHITE/ALUMINIUM
IP Rating
IP20
Color Rendering
CRI 90
Driver
ON/OFF DRIVER

See more
