WEVER & DUCRE

Ginko 2. 4 Outdoor surface mounted projector light (ceiling, wall, ground, spike), housing made of ANTICORODAL 6082 low-copper-content aluminium alloy for excellent resistance to corrosion, made entirely on a CNC lathe. Bracket in AISI 316L stainless steel, tumble finished and painted (painted version), body made of brass, produced entirely on a CNC lathe. Bracket made of brass. Optics available: 9°-36°° . IP66, IK07.

A single-emission projector with a super warm white 2700K LED (CRI 80) delivering 1265 lm at 140.6 lm/W. Made of AISI 316 steel with an electropolished finish and extra-clear tempered glass diffuser. IP68-rated, weighing 1.2 kg, with a 13W power consumption. Includes a 1m power cable, protection class II, and can be wall, ceiling, or floor-mounted. Compliant with EN 60598-1.

Luminaire housing made of dezincificationresistant cast brass. Water pressure-tight underwater floodlight for the illumination of non-accessible ponds, pools and water features with a depth up to 20 metres. The cast brass used in these luminaires is the optimal material for long-term underwater use. The material is approved for drinking water and is resistant to sea wateR. IP68,IK09.

The Energi Savr Node (ESN) family is a group ofmodular products for the control of lighting loads. 0-10 V/switching power module can be used in anAthena system.• Includes QS link for seamless integration of lightsand controls.• Auto sink and source capability for 0 –10 V- outputs.• Buttons on the module provide override control.• LEDs on the module provide diagnostic information.• 0-10 V/switching power module can be used for0 –10 V- and switching applications only.
