LINEALUX L5 LS9050_ 23W

The Linealux L5 Generation 2 is a high-power, architectural grade luminaire that combines technology and performance in a stylish linear form factor. Packed with features including EasyGlow™ visual comfort CoolDrive™ thermal management technologies and MicroAntileach™. PowerSync™ allows for highly granular digital control via common protocols. Unique and flexible optics allow wide end-to-end spacing whilst maintaining excellent uniformity. Designer lens options are offered as standard to provide

Specification

Power
LED 23W/300MM
Color Temperature
TUNNABLE WHITE 2700K
Light Source Type
LED
Lumen Output
8460LM/300MM
Finishing
ALUMINIUM
IP Rating
IP66
Color Rendering
CRI 80
Driver
DMX 512

See more

ERCO
SURFACE MOUNTED DOWNLIGHT
OUTDOOR LIGHTING

Surface-mounted downlight housing are made of crrosion-resistant cast aluminium. No-Risen surface treatment. Double powder-coated and tamper-proof screw. Screw-fastened cover frame with safety glass, IP65.

LINEALIGHT
INGROUND UPLIGHT
OUTDOOR LIGHTING
Single emission uplights for outdoor application. The super warm LED light source with a spot light distribution is composed of 1 arrayled LEDs. Luminaire body is made of die-cast aluminium en ab - 46100 and features a black finish, processed by means of open pore anodizing + powder coating; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP68
LINEALIGHT
RECESSED DOWNLIGHT
INDOOR LIGHTING
Single emission downlights for indoor application. The warm white LED light source with a spot light distribution is composed of 1 powerled LEDs. The device body is made of aluminium 6026 and features a embossed white ral 9003 finish, processed by means of powder coating; the diffuser is made of uv resistant polycarbonate. The ingress protection degree is IP44; the total weight is of 0.128 kg. The power supply driver is not provided and is to be ordered separately. The power supply cable is included and features a 0.170 m length. The device features protection class III and can be ceiling-mounted, with a 35 mm diameter hole (in plasterboard). Compliant with the EN 60598-1 standard and its specific provisions.
FORMALIGHTING
WALLWASHER
INDOOR LIGHTING
EVO track mounted Zero Compasso wallwasher, available in three sizes (Ø42, Ø66 and Ø100mm) versatile aiming angletiltable vertically 0°-90° and rotatable horizontally 360°. Available in regular and long arm version for deep recessed and pendant EVO track. Perfect for museums and galleries applications. Wallwashing with high uniformity can be used to illuminate artwork and sculptures. Vertical uniformity creates a wide and distinguished spatial impression by brightening the entire height of the wall. DALI dimmable fixtures can also be controlled by Casambi DALI Broadcast device.
