XAL

SURFACE MOUNTED DOWNLIGHT
INDOOR LIGHTING
SASSO 100 R0UND ADJ_048-34105311M

Cylindrical surface mounted spotlight in die-cast aluminium; suitable for ceiling mounting; surface black powder coated; Inner colour lacquered in black; 360° rotatable and 20° tiltable; luminaire housing can be attached to mounting plate without tools by interlock; passive cooling of the LEDs. The ingress protection degree is IP20.

Specification

Power
20.2W
Color Temperature
3000K
Light Source Type
LED
Lumen Output
1400LM
Finishing
BLACK
IP Rating
IP20
Color Rendering
CRI >90
Driver
DALI DRIVER

See more
