LINEALIGHT

Low profile recessed channel, height 13 mm; suitable for rimless installation in 12.5mm plasterboard ceilings;

specially designed trim with grooves for better adhesion of smoothing compound; suitable for wall or ceiling

mounting; surface white powder coated; easy mountng without need to cut the substructure; fall-safe light inset

made of extruded aluminium profile, can be inserted in the canal without tools by magnetic holders; side

coupled light directed downward through LGP .

Fixed and adjustable in one; When tilting at any angle, patented spherical shielding design helps prevent light leak and gap. Special moving gear tilt design provides stabilized torque for accurate tilt with sound and force feedback when rotating. Besides, Bach 5s series have pull ring equipped for easy maintenance and internal angle mark for accurate aiming. Professional optics, precise and round light spot.

Recessed or Surface mount magnetic track system containing linear light, spot light, wall washer and pendant light module to create your imagination of illumination purposes in a wonderful visual experience. Low voltage DC48V plus double insurance installation system magnetic + click make it work safely.

Pivot 1.7 outdoor applications surface mounted (ceiling, wall, floor) housing made of ANTICORODAL EN AW 6082 low-copper-content aluminium alloy for excellent resistance to corrosion, made entirely on a CNC lathe. Bracket in AISI 316L stainless steel, tumble finished and painted (painted version), body made of brass, produced entirely on a CNC lathe. Bracket made of brass. Optics available for 5°, 8°, 11°, 17°, sharp 21°, 34°, 43°, 45°, sharp 51°, 54°, 15°x47°, 46°x16°. IP66,IK07.
