IN30_ MJ50.12

Direct emission modular lighting system with LED lamps. Initial module for general lighting (Low Contrast); can be used independently or in a continuous line. Minimal (frameless) version extruded aluminium single length profile; methacrylate opal screen set up for connection to end caps on both sides. Installation can be recessed, surface-mounted (ceiling/wall), or pendant. The module must be completed with the accessories kit needed for the selected type of installation.

Specification

Power
19W/1.2M
Color Temperature
3000K
Light Source Type
LED
Lumen Output
1887LM/M
Finishing
ALUMINIUM
IP Rating
IP20
Color Rendering
CRI 80
Driver
DALI DRIVER

See more
