Product Detail | Bloxlimited

WAKO

WALLWASHER

INDOOR LIGHTING

NANO NF252 - 20D

NANO wall washer luminaire is made of high illuminance uniform, light distribution, single bin and compact size. Adjustable lighting angle. DIMENSION: 18 mm (W) x 15.5 mm (H). Unit Length 1000mm 500mm 300mm. Number of LED per meter 60, LED Type NICHIA. CRI 80 90 Lifetime 50000 hrs Lumen Power Input 350mA Constant Current, Dimming 0-10V 1-10V DALI DMX PWM, IP20.

Specification

Power

20W/M

Color Temperature

3000K

Light Source Type

LED

Lumen Output

1670LM/M

Finishing

WHITE

IP Rating

IP20

Color Rendering

CRI90

Driver

1-10V DRIVER

LIGMAN

INGROUND UPLIGHT

OUTDOOR LIGHTING

Die-cast aluminium housing. Pre-treated before powder coating ensuring high corrosion resistance. 5.5 mm thick front ring in grade 316 stainless steel. Single cable entry, through wiring upon request. Stainless steel fasteners in. Recessing box in high-density polyethylene is included. Suitable for drive-over with a maximum load of 2000 kg. Vehicles with pneumatic tires can drive over the luminaire but the speed must not exceed 50 km/h. Load is transferred by the housing to the foundation. The distance between the floodlight and the illuminated surface should be at least 0.5 m

LINEALIGHT

INGROUND UPLIGHT

OUTDOOR LIGHTING

Single emission uplights for outdoor application. The warm white LED light source with a medium flood light distribution is composed of 9 powerled LEDs. The luminaire body is made of aisi 316 steel and features a steel finish; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP67, IK10.

MEYER

UP/DOWN WALL LIGHT

OUTDOOR LIGHTING

Housing made corrosion‑resistant die‑cast aluminum AlSi12, polyester powder coated by high‑quality and UV‑stabilized coating process, Colour: black ral 7021, all exterior parts are stainless steel, UV stabilised, impact‑resistant polycarbonate cover , silicon gasket, with 4 stainless steel screws, wall arm: 2 drilled holes Ø 6,5 mm, spacing 282 mm, tilt range: 310°, cable gland: PG11, connecting terminal: 3 pole, highly efficient optics made of transparent thermoplastic for precise lighting tasks, integral driver (AC/DC), CRI > 80, max 2 SDCM, service life L90/B10 > 50.000 h, Beam angle (fwhm): 15° / 103°, luminous flux: 1175 lm, wattage: 15 W, delivered lumens 78 lm/W, protection type IP65, protection class I, impact resistance IK10, windage area 0,04 m², dimensions (L×H×W): 328 × 47 × 135 mm, weight 3.3 kg. The modular luminaire design makes the replacement of components possible. The product meets the demands of the applicable EU guidelines and product safety regulations and bears the CE mark. Customized solutions and modifications are possible: Special ral, db or ncs colours as polyester powder coat, luminaires in 2700 K and other colour temperatures and versions for high ambient temperature.

FORMALIGHTING

TRACKLIGHT

INDOOR LIGHTING

The TicTok series is an energy-saving micro track system with an integrated driver, which focuses on modularity and ecofriendliness. The tool-free interchangeable LED module facilitates design flexibility and ease of on-site maintenance. Designed to be the perfect solution for accent lighting in sustainable lighting design schemes for retail, hospitality, and high-end residential. TicTok curved is designed to be fitted on the curved Micro Track with R300 or R500; to ensure that the design environment is fully covered.
