SPARK

Edgeless luminaire · Photometric cover: Opal (PMMA) · "KORONA FRAME" ·

"MATTER"- Standard · 3-pole terminal block · 240 Volt, 50/60 Hz · Direct light

colors: optionally 3000K or 4000K. · LED board coated with high-reflective material

· MacAdam: 3 · 50,000 hours lifespan · Flicker-free operation with suitable electronic

ballast · Light source can be replaced by professional staff. · IP protection type IP20 ·

Electrical Protection Class 1 · complies with EN 60598-1 · · · · · · · · · · Height: 85 m

Single emission uplights for indoor application. The super warm LED light source with a diffused light distribution is composed of 1 powerled LEDs with CCT of 2700 K and a CRI 80; the source luminous flux is 60 lm, with a 85.7 lm/W nominal luminous efficacy. The device body is made of ot58 brass and features a chrome finish, processed by means of galvanic chromium plating; the diffuser is made of extra clear glass - tempered with a sandblasting treatment. The ingress protection degree is IP44.

Single emission lines for outdoor application. The warm white LED light source with a diffused light distribution is composed of 60 stripled LEDs. The device body is made of aluminium 6060 and features a anodised aluminum finish, processed by means of 20 µm anodizing; the diffuser is made of silicone resin. The ingress protection degree is IP66; the total weight is of 0.200 kg. The power supply driver is not provided and is to be ordered separately. The power supply cable is included and features a 0.220 m length. The device features protection class III and can be wall lights or ceilingmounted. Compliant with the EN 60598-1 standard and its specific provisions

Rectangular recessed multi-downlight made of die-cast aluminium; installation without tools in mounting set due to patented ball catch system; rectangular installation housing; for trimless installation in plasterboard ceilings; suitable for ceiling thickness of 12.5/15/20/25 mm; equipped with three flood round light elements; symmetrical light distribution with precise radiation characteristic, beam angle 49°; high quality reflector with micro-faceted.
