FLOS

I-BRICK is a range of wall recessed luminaires with LED light sources plus a good glare control allows it to be installed in most places where a comfortable illumination is needed. The low energy consumption LED module saves operating cost while providing acceptable lighting levels. I-BRICK is available in five different styles in two size. The shallow housing can be installed in either wall or step where recess depth is limited. The high quality LED drivers is integrated inside the luminaire for ease of installation. I-BRICK is commonly used to illuminate stairways, pathways and walls.

surface-mounted light · Photometric covers optional: Opal (PMMA), Microprism,Crystal or Industrial · invisible weld seams · no visible screws · RAL colors on request ·

28 colors possible · 240 Volt, 50/60 Hz · not dimmable · 3-pole terminal block ·Direct light colors: optionally 2700K, 3000K, 3500K or 4000K. · LED board coatedwith high-reflective material · CRI > 90 · MacAdam: 3 · 50,000 hours lifespan ·Flicker-free operation with suitable electronic ballast ·

Esem Mid 1.1

recessed downlight for indoor applications; recessed (ceiling, wall, shelf); Power consumption: max 3W (3 power LEDs x 1W); Power supply: max 350mA; Lumen output at source: 309 lm (3000K, 350mA); Delivered lumen output: 220 lm (3000K, 350mA, 22°); 3 power LEDs, 1/4 ANSI BIN, 50 000h L95 B10 (Ta 25°C); LED colour: 2700K, 3000K, 4000K, 5000K; Optics: 11° tiltable ±20°, 22° tiltable ±20°, 30° tiltable ±20°, 20°x45° tiltable ±20°; CRI Colour Rendering Index: 80

ATHLON family is functional mini spotlight/ floodlight. The slim and clean design of Athlon allows a hidden installation. Athlon is designed for a streamlined time effective installation. Alanod Miro reflectors used in this luminaire are designed by Photopia high-end lighting engineering software. Tigh beam control utilizes selected lenses from world-renowned manufacturers. ATHLON is available with symmetric, asymmetric and bisymmetric light distributions and the broad range of accessories such as a ground, spike, tree strap, color filters, honey comb louver and glare shield hook makes it a dynamic floodlight choice. The graduated scale provides accuracy of the light distribution on the illuminated surface. ATHLON is suitable to light up small to medium sized objects or areas such as signage boards, ceiling, building facades, etc.
