RCL

ADJUSTABLE DOWNLIGHT

INDOOR LIGHTING

DRX5-Static-White-1400m-50-Zoom- 3000K

DRX5 is a compact recessed luminaire that masters the art of pin spotting and accent lighting while combining excellent beam quality with all the benefits of RCL technology. The DRX5 is available with three fixed CCT light engines, delivering up to 1,474 lumens from a wide selection of fixed beam options as well as zoom powered by Lensvector. DRX5 is also available with Tunable White and RGBW - visit their specsheets to learn more.

Specification

Power

17W

Color Temperature

3000K

Light Source Type

LED

Lumen Output

1309LM

Finishing

WHITE

IP Rating

IP20

Color Rendering

Driver

1-10V DRIVER

LINEALIGHT

RECESSED DOWNLIGHT

INDOOR LIGHTING

Single emission downlights for indoor application. The warm white LED light source with a medium flood light distribution is composed of 1 powerled LEDs. The device body is made of aluminium 6026 and features a embossed black ral 9005 finish, processed by means of powder coating; the diffuser is made of uv resistant polycarbonate. The ingress protection degree is IP44; the total weight is of 0.078 kg. The power supply driver is notprovided and is to be ordered separately. The power supply cable is included and features a 0.170 m length. The device features protection class III and can be ceiling-mounted, with a 29 mm diameter hole (in plasterboard) with an outer casing, code 99847 (for concrete or masonry). Compliant with the EN 60598-1 standard and its specific provisions

SPARK

WALLWASHER

INDOOR LIGHTING

Recessed linear wallwasher, luminaire body made of aluminium housing with white powder coated trim finish. Black finish available upon request.

IGUZZINI

SURFACE LINEAR LIGHT

OUTDOOR LIGHTING

Direct light luminaire, designed to use monochrome LED lamps, DALI 48Vdc dimmable with searching and addressing function. Ceiling-, wall- or surface-mounted. Consists of a body and supports for installation, to be ordered separately. The body is made of extruded aluminium and includes die-cast aluminium end caps with 50/60 Shore A silicone seals. IP66,IK06.
