KOIZUMI

SURFACE LINEAR LIGHT

INDOOR LIGHTING

XH 47257L

DIMMABLE Vertical mount / Wall mount linear light designed as an essential component of the architectural space in which it is used. A high quality light product with a focus on having a solid feel and continuity. Creates a unique lighting environment with various mounting methods, lengths, color temperatures, and control methods.

Specification

Power

32.4W/1.2M

Color Temperature

3000K

Light Source Type

LED

Lumen Output

3490LM/1.2M

Finishing

ALUMINIUM

IP Rating

IP20

Color Rendering

CRI 82

Driver

0-10V DRIVER

FLOS

SURFACE TRACKLIGHT

INDOOR LIGHTING

Accent lighting LED module to be installed in The Running Magnet System. Built-in DC/DC electronic voltage converter

CUSTOMIZED

CEILING LIGHT

INDOOR LIGHTING

FOR BIG C PATTAYA3 (BIG C STORE)

LINEALIGHT

WALLWASHER

OUTDOOR LIGHTING

Single emission lines for outdoor application. The warm white LED light source with a flood light distribution is composed of 9 powerled LEDs. The device body is made of aluminium 6060 and features a anodised aluminum finish, processed by means of 20 µm anodizing; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP67; the total weight is of 2.8 kg. The power supply cable is included and features a 0.2 m length. The device features protection class I and can be wall lights or floormounted with an outer casing, code 98672(for concrete or masonry). Compliant with the EN 60598-1 standard and its specific provisions.

IGUZZINI

SPOTLIGHT

OUTDOOR LIGHTING

Spotlight designed to use LED lamps and a Spot optic. The optical assembly and base is made of EN1706AC 46100LF aluminium alloy and subjected to a multi-step, pre-treatment process, in which the main phases are degreasing, fluorozirconation (a protective surface film) and sealing (with a nano-structured silane layer). The following painting stage consists of a primer and a liquid acrylic paint, cured at 150°C, with a high level of weather and UV ray resistance. 5 mm thick tempered sodium-calcium closing glass. Double adjustability allows a 360° rotation about the vertical axis and 90° tilting relative to the horizontal plane. Mechanical aiming locks for rotation on both the vertical axis and horizontal plane. IP66,IK07.
