Light source: High density, LM80 proved. Process & Material: High light transmittance, environmental silicone material, integrated extrusion molding technology. Optical Design: Unique optical light distribution structure design, uniform lighting surface and no shadow. Appearance Design:Super small model, compact and simple, unique design. Product Certification: CE、ROHS. Environmental Features: Resistance to saline solutions, acids & alkali, corrosive gases and UV. Working/Storage Temperature: Ta:-25~55℃ / 0℃～60℃. Application:Interior outline, Furniture supporting lighting. Indoor 3-year warranty, working life ≥ 36000 hours.

Round fixed luminaire designed to use LED lamps with C.o.B. technology. Version with rim for surface-mounting. Prismatic thermoplastic reflector complete with flux enhancer and metallised flap to guarantee optimum vertical downlight. Dissipater made of painted grey die-cast aluminium.

Floor or ground-recessed luminaire designed to use white monochrome LED lamps, a fixed optic and powered with a continuous current of 350/500mA. The round frame with no visible screws and the optical assembly are made of AISI 304 stainless steel with an extra-clear, sodium-calcium tempered glass cover. The luminaire is fixed to the outer casing using special locking seals that hold it in place. The unit comes complete with LED circuit and methacrylate lens. The product's wiring system features an A2 stainless steel cable gland with a 1800 mm long H05RNF type 2x1 mm² output power cable. The cable is equipped with an anti-transpiration device (IP68) that consists of a silicone-coated joint located on the power cable. An outer casing is available for installation and can be ordered separately from the plastic optic assembly. The glass unit, optical assembly, frame and outer casing together guarantee a maximum static load resistance of 2000 kg. The maximum surface temperature of the glass is less than 40°C.
