LUCE & LIGHT

BOLLARD

OUTDOOR LIGHTING

Linear 2.1

bollard for outdoor applications, single beam; surface mounted (floor); Power consumption: 8,5W; Power supply: 230Vac; Lumen output at source: 657 lm (3000K, 8.5W); Delivered lumen output: 284 lm (3000K, 8.5W); 1 high-intensity power LED, 3-step MacAdam, 50 000h L90 B10 (Ta 25°C); LED colour: 2700K; Optics: asymmetrical; Upward flux fraction: 1,05% (4W), 0,87% (8,5W); CRI Colour Rendering Index: 80; Body material: head in aluminium, column in anticorodal aluminium; Finishes: anthracite; RAL fin

Specification

Power

8.5W

Color Temperature

2700K

Light Source Type

LED L90 B10

Lumen Output

284 lm

Finishing

BLACK

IP Rating

IP65

Color Rendering

CRI 90

Driver

PLATEK

FLOODLIGHT

OUTDOOR LIGHTING

Surface Floodlight in die-cast body aluminium alloy with very low copper content. The product is painted continuous two step paint process (epoxy-based primer + polyester base color finisg) which allows to generate a single thick protective coating which generates aprotective barrier against atmospheric agents and UV rays. IK07

LINEALIGHT

WALLWASHER

OUTDOOR LIGHTING

Single emission lines for outdoor application. The warm white LED light source with a elliptical light distribution is composed of 12 powerled LEDs. The device body is made of aluminium 6060 and features a anodised aluminum finish, processed by means of 20 µm anodizing; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP68; the total weight is of 1.020 kg. The power supply cable is included and features a 0.250 m length. The device features protection class II and can be floor-mounted with an outer casing, code 99762 (for concrete or masonry). Compliant with the EN 60598-1 standard and its specific provisions.

ACCLAIM

SURFACE LINEAR LIGHT

OUTDOOR LIGHTING

Part of the extensive Linear One® family, these attractive aluminum-bodied, natatorium-ready (IP66) linear fixtures are available in 1’ and 4’ lengths and are easily interconnected in series to simplify installation. Flexibility is key, with a wide choice of configuration combinations, including: multiple emitter types, a full range of TIR optics, plus glare shields and louvers. All of which are fulfilled through our Acclaim Modular system in Los Angeles to ensure industry-leading delivery times. Control is achieved using the industry standard DMX-512A format, with RDM for remote configuration. The internal auto-sensing power supply within each unit can accept mains inputs between 100 to 277VAC at 50 or 60Hz.

XAL

RECESSED SPOTLIGHT

INDOOR LIGHTING

Round spotlight element in aluminium; surface black powder coated; installation without tools in mounting set due to patented ball catch system; recessed light with wrap around edge; suitable for ceiling thickness of 2-25 mm; spotlight element height adjustable without tools: flush with the ceiling, or extended 25 mm or 35 mm; 360° rotatable and 90° tiltable; passive cooling of the LEDs through improved heat sink geometry; with COB (Chip on Board) technology for maximum efficiency;
