SIMES

INGROUND UPLIGHT

OUTDOOR LIGHTING

S.7016W

To-be-fixed supports and recessing box in extruded anodized EN AW-6060 aluminium housing (copper free) with high corrosion resistance. Toughened glass diffusor 15 mm thick for CONTINUOUS LINE FULL-GLASS. Extruded polycarbonate diffuser 3mm thick for CONTINUOUS LINE POLYCARBONATE. Luminaire hard wired with single neoprene cable with cable gland. Fixing bases and recessing box included. Fast connector IP67 included.

Specification

Power

LED 5 W

Color Temperature

3000K

Light Source Type

LED

Lumen Output

360 lm

Finishing

White

IP Rating

IP67

Color Rendering

CRI 80

Driver

On/Off

LUCE & LIGHT

SPOTLIGHT

OUTDOOR LIGHTING

projector for outdoor applications; surface mounted (ceiling, wall, floor), surface mounted (ceiling, wall, ground, spike); Power consumption: 25W;

Power supply: 24Vdc; Lumen output at source: 1890 lm (3000K, CRI 90); Delivered lumen output: 1575 lm (3000K, 13°, CRI 90); 1 COB LED, 2-step

MacAdam, 55 000h L70 B10 (Ta 25°C); LED colour: 2700K; Optics: 42°; CRI Colour Rendering Index: >90

SPARK

SURFACE MOUNTED DOWNLIGHT

INDOOR LIGHTING

Surface mounted downlight, luminaire body made of aluminium housing with white powder coated finish. Reflector finish available White, Silver and Black Chrome. Black finish and honeycomb accessory available upon request.

LINEALIGHT

WALLWASHER

OUTDOOR LIGHTING

Single emission lines for outdoor application. The warm white LED light source is composed of 18 powerled LEDs. The device body is made of aluminium 6060 and features a anodised aluminum finish, processed by means of 20 µm anodizing; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP67; the total weight is of 11 kg. The total absorbed power is 89 W. The power supply cable is included and features a 0.17 m length. The device features protection class I and can be floor-mounted with an outer casing, code 99772 (for concrete or masonry). Compliant with the EN 60598-1 standard and its specific provisions.

LINEALIGHT

RECESSED DOWNLIGHT

INDOOR LIGHTING

Single emission downlights for indoor application. The warm white LED light source with a flood light distribution is composed of 1 powerled LEDs. The device body is made of aluminium and features a white ral 9010 finish, processed by means of coating. The ingress protection degree is IP45; the total weight is of 0.070 kg. The power supply driver is not provided and is to be ordered separately. The power supply cable is included and features a 0.12 m length. The device features protection class III and can be ceiling-mounted, with a 35 mm diameter hole (in plasterboard). Compliant with the EN 60598-1 standard and its specific provisions.
