SIMES

INGROUND UPLIGHT
OUTDOOR LIGHTING
S.5942W.19
Die-cast EN AB-44100 and extruded EN AW-6060 aluminium housing (copper free) with high corrosion resistance. Marine grade stainless steel AISI 316L front trim 3 mm thick. Toughened glass diffuser 6 mm thick for MINILINEAR Full-Glass, 10 mm thick for MINILINEAR Stainless Steel, 10 mm thick for LINEAR Stainless Steel. 99.98% pure aluminium reflectors. Stainless steel screws. Luminaire hard wired with single neoprene cable with cable gland. Silicone gaskets. Recessing box in stainless steel. Fast connector IP68 included.

Specification

Power
LED 32 W
Color Temperature
3000K
Light Source Type
LED
Lumen Output
2550 lm
Finishing
Sliver
IP Rating
IP68
Color Rendering
CRI 90
Driver
On/Off

See more

SPARK
MAGNETIC TRACKLIGHT
INDOOR LIGHTING

Magnetic track system come with RECESSED mount or SURFACE mount version. Module available LED Diffused linear, LED Spot linear, LED Spot light etc. Input Voltage 48VDC

DIMENSION : Ø36*90*125mm


CDN LIGHTING
RECESSED DOWNLIGHT
INDOOR LIGHTING


SIMES
INGROUND LINEAR LIGHT
OUTDOOR LIGHTING
Fixing base and recessing box in extruded anodized EN AW-6060 aluminium housing (copper free) with high corrosion resistance. Mechanical resistance IK 10 Maximum load capacity 500 Kg. This luminaire contains built-in LED modules. In case of damage or malfunction please contact the manufacturer to receive additional instructions on how to replace and relative spare parts to order. The LED modules cannot be handled in the luminaire by the end user. This product contains a light source of energy efficiency class: G. LED modules are engineered accordingly to the existing regulations of Lumen Maintenance (LM80) and Technical Memorandum (TM21), where uniformity and quality of the light is 70,000 hours referred to L80 B10 Ta 25 ° C (50,000 hours referable to L80 B10 Ta 40°C). Lifespan of the luminaire min. 50,000 hours at 40°C. Performance Ambient temperature Tq 25°C. Operating ambient temperature range is from -20°C to +50°C. Storage temperature range from -20°C to +60°C.
LINEALIGHT
WALLWASHER
OUTDOOR LIGHTING
Single emission lines for outdoor application. The warm white LED light source with a elliptical light distribution is composed of 27 powerled LEDs. The device body is made of aluminium 6060 and features a anodised aluminum finish, processed by means of 20 µm anodizing; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP67; the total weight is of 7 kg. The power supply cable is included and features a 0.2 m length. The device features protection class I and can be wall lights or floormounted with an outer casing, code 99760 (for concrete or masonry). Compliant with the EN 60598-1 standard and its specific provisions.
