LUMASCAPE

In-ground wall washer up light makes it possible to fully illuminate a vertical surface, like façade and from the ground to the lower edge of the roof. The lower limit of the light distribution is a straight line, without the usual “light cone”. The luminaires can be driven over by vehicles with pneumatic tyres. Luminaire must not be used for installation in road lanes, where the fixture is exposed to a horizontal strain due to braking, acceleration and change of direction. Luminaire cover made of cast bronze and luminaire housing made of cast aluminium. Recess housing made of stainless steel. Reflector surface made of pure aluminium. IP67, IK10

DIMENSION : Ø345*H110MM

Direct light luminaire, designed to use monochrome LED lamps, DALI 48Vdc dimmable with searching and addressing function and transparent glass cover. Ground-, wall- and ceiling-recessed. Option of installation in continuous lines of up to a max length of 10.5m only for ground-recessed installation. Made up of a body, end caps, an outer casing and caps to be ordered separately. Extruded aluminium body, with die-cast aluminium end caps complete with silicone seals. The ingress prtection degree is IP66,IK10.

Single emission lines for outdoor application. The warm white LED light source with a asymmetric wallwasher light distribution is composed of 96 topled LEDs. The luminaire body is made of aluminium 6060 and features a anodised aluminum finish, processed by means of 20 µm anodizing; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP68,IK08.

Single emission downlights for indoor application. The warm white LED light source with a wide flood light distribution is composed of 1 arrayled LEDs. The device body is made of die-cast aluminium en ab - 46100 and features a embossed black ral 9005 finish, processed by means of powder coating; the diffuser is made of uv resistant polycarbonate. The ingress protection degree is IP44; the total weight is of 0.511 kg. The power supply driver is not provided and is to be ordered separately. The power supply cable is included and features a 0.300 m length. The device features protection class III and can be ceiling-mounted, with a 91 x 91 mm hole (in plasterboard). Compliant with the EN 60598-1 standard and its specific provisions.
