Products

TRAXON

LED DOT
OUTDOOR LIGHTING
Media Dot Plus L

Media Dot Plus is an easy way to create pixel-controlled, full-color effects or digital media on walls, buildings, monuments—anywhere you can imagine. Our three Media Dot Plus models provide ultra-long daisy-chains and feature integrated color correction for vibrant and true-to-life displays. Select from our versatile installation accessories the deliver a simple, full package for your design vision.

Specification

Power
3W/DOT
Color Temperature
RGB
Light Source Type
LED
Lumen Output
33.3LM/W
Finishing
BLACK
IP Rating
IP67
Color Rendering
CRI>80
Driver

See more

LINEALIGHT
WALLWASHER
OUTDOOR LIGHTING
Single emission lines for outdoor application. The warm white LED light source is composed of 12 powerled LEDs. The device body is made of aluminium 6060 and features a anodised aluminum finish, processed by means of 20 µm anodizing; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP68; the total weight is of 1.020 kg. The power supply cable is included and features a 0.250 m length. The device features protection class II and can be floor-mounted with an outer casing, code 99913 (for concrete or masonry). Compliant with the EN 60598-1 standard and its specific provisions.
LINEALIGHT
WALLWASHER
OUTDOOR LIGHTING
Single emission lines for outdoor application. The warm white LED light source with a medium flood light distribution is composed of 12 powerled LEDs. The device body is made of aluminium 6060 and features a anodised aluminum finish, processed by means of 20 µm anodizing; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP68; the total weight is of 1.020 kg. The power supply cable is included and features a 0.250 m length. The device features protection class II and can be floor-mounted with an outer casing, code 99762 (for concrete or masonry). Compliant with the EN 60598-1 standard and its specific provisions.
LUCI
LED STRIP
OUTDOOR LIGHTING

2 types of LED pitch (7.1 or 17.8mm) for profile and cove lighting.

The 5 wattage options, ranging from 2 to 15W/m, utilize the same LED package to ensure consistent CCT.

High efficient LED package achieving up to 185 lm/W.


LINEALIGHT
WALLWASHER
OUTDOOR LIGHTING

Single emission led strip for outdoor application. The warm white LED light source with a flood light distribution is composed of 108 topled LEDs. The luminaire body is made of technopolymer and features a white finish; the diffuser is made of pu. The ingress protection degree is IP67
