TRAXON

A single-emission projector with a super warm white 2700K LED (CRI 80) delivering 1265 lm at 140.6 lm/W. Made of AISI 316 steel with an electropolished finish and extra-clear tempered glass diffuser. IP68-rated, weighing 1.2 kg, with a 13W power consumption. Includes a 1m power cable, protection class II, and can be wall, ceiling, or floor-mounted. Compliant with EN 60598-1.

"Copper Free" Aluminium die cast housing in EN AB-44100 with high resistance against corrosion. Stone wash surface treatment prior to painting process. A4 grade Stainless Steel screws with 2,5-3% molybdenum content which increases the resistance against corrosion. Pre treated Silicone Gaskets. Painting Process : 3 Step Process: 1) Surface treatment with BONDERITE. A heavy metal free chemical surface treatment containing ceramic nano particles giving a cohesive, inorganic and highly dense protective coating. 2) PRE POLYMERIZATION a process of introducing an epoxy primer with excellent characteristics to the paint which also offers very high resistance to oxidation due to its Zinc content. 3) POLYMERIZATION a process with the application of polyester powder with high resistance against UV rays and harsh weather conditions. Resistance test protection for Marine applications for 1200h. Mechanical resistance IK 09 Maximum load capacity 1000 Kg. This luminaire contains built-in LED modules. In case of damage or malfunction please contact the manufacturer to receive additional instructions on how to replace and relative spare parts to order. The LED modules cannot be handled in the luminaire by the end user. This product contains a light source of energy efficiency class: E. LED modules are engineered accordingly to the existing regulations of Lumen Maintenance (LM80) and Technical Memorandum (TM21), where uniformity and quality of the light is 70,000 hours referred to L80 B10 Ta 25 ° C (50,000 hours referable to L80 B10 Ta 40°C). Lifespan of the luminaire min. 50,000 hours at 40°C. Performance Ambient temperature Tq 25°C. Operating ambient temperature range is from -20°C to +50°C. Storage temperature range from -20°C to +60°C.

Luminaire for ceiling, wall, or surface installation, available in monochromatic, RGBW, Tunable White, and Tunable Warm LED. Made of extruded aluminium with die-cast zamak end caps and liquid acrylic coating for durability, it features a sealed optical compartment with 5mm glass. Offers multiple optics—Wall Grazing, Microlouvre, Accent, Flood, and No-Dot—with various beam options. Available in 2200K–4000K, RGBW, and Tunable White versions. Rated IP66, IK06, with A2 stainless steel screws (driver

TicTok main voltage track enables users to create unique lighting schemes and configurations. Energy-saving, track mounted on a main voltage 3-phase track system, with an integrated driver in the track adaptor - the focus is on eco-friendly design and modularity. A ready-to-use solution for greater flexibility, energy efficiency, and sustainability. TicTok is an excellent and flexible accent lighting solution for restaurants, residential spaces, retail and galleries. TicTok main voltage track is available for Ø45, Ø58 and Ø75 spot heads, with versatile aiming angle tiltable 0°-70° and rotatable 360°. TicTok is available with Casambi or DALI control options.
