TRAXON

ION S Medium Track Spotlight with beam shaper optics paired with On-board dimming. Beam Shaper Optics capable of illuminating a square frame between 500-800mm in length at 2000mm distance.

DIMENSION : Ø65mm x 228mm

FUSION FF3

FF3-9304007F-BB

Square recessed ceiling downlight made of die-cast aluminium with black powder-coating finish (RAL 9005) and black reflector; ON-OFF Driver; LED 7W; measurement 98mm x 45mm; ceiling cutout of 90mm x 37mm with a narrow mounting trim; luminaire's weight is approximately 180g; CCT 3000K with an LED Output of 650lm; high color rendering at an index of CRI90; after a lifetime of 50000h min. 80% of the luminous flux with energy efficient OSRAM LED Chips; 5 years warranty; beam characteristic with 40° beam angle; lighting perfectly suitable for reading, writing as well as computer and control work according to DIN EN 12464-1 (UGR<10); degree of housing protection according to DIN EN 60529 (IP20)

Recessed inground uplight luminaire ,made of stainless steel housing, installation bush made of polyamide and white safety glass. Drive-over luminaire from vehicles with pneumatic tyres. Dust-tight and water pressure tight. Maximum submersion depth 20m. IP68,IK10.

Rectangular suspended luminaire is made of rounded edges in aluminium housing. Extremely flat (only 15mm) and slim (only 295mm) design. Modern shape in an elegant design for high demands. Surface white powder coated. Suspended luminaire with 1500mm cable suspension. Direct/indirect light distribution; side coupled light, directed up and down; light control via a specially made indirect diffuser; microprismatic PMMA cover. DIMENSION: (L)1180x(W)180X(H)15mm.
