Products

IGUZZINI

RECESSED DOWNLIGHT
INDOOR LIGHTING
RA72 .43

Linear miniaturised recessed luminaire with 5 optical elements for LED lamps - fixed optics.

Specification

Power
12.4W
Color Temperature
3500K
Light Source Type
LED
Lumen Output
782.1LM
Finishing
WHITE
IP Rating
IP23
Color Rendering
CRI 90
Driver
ON/OFF DRIVER

See more

XAL
LINEAR DOWNLIGHT
INDOOR LIGHTING
Rectangular recessed multi-downlight made of die-cast aluminium; installation without tools in mounting set due to patented ball catch system; rectangular installation housing; with trim jet black; suitable for ceiling thickness of 2-25 mm; equipped with four wide flood round light elements; symmetrical light distribution with precise radiation characteristic, beam angle 72°; high quality reflector with micro-faceted, aluminum-vaporised surface; chrome reflector; passive cooling of the LEDs through improved heat sink geometry; light colour 3000 K; binning initial MacAdam ≤ 3 SDCM; CRI ≥ 90; min. 90% of luminous flux after 50000 operating hours; energyefficient high power LEDs with very good colour rendering; degree of protection IP20; PC2; incl. converter, non dimmable; through wiring connection box, 3-pole or 5-pole, available as an accessory; accessories are listed separately; light source not replaceable; control gear replaceable by an authorized professional; clank-free
LINEALIGHT
LED NEON TUBE
OUTDOOR LIGHTING

Radial diffusion led strip for indoor or outdoor application. The warm white LED light source with a diffused light distribution is composed of 2560 topled LEDs. The luminaire body is made of silicone and features a opaline finish; the diffuser is made of silicone. The ingress protection degree is IP65.

BEGA
SURFACE MOUNTED DOWNLIGHT
OUTDOOR LIGHTING
Compact downlight with symmetrical narrow beam light distribution. Luminaire made of aluminium alloy, aluminium and stainless steeL. IP65,IK08.
WE-EF
INGROUND UPLIGHT
OUTDOOR LIGHTING

IP69. IK10+. Stainless steel construction including PCS hardware. Safety glass lens, max. load 5 tonnes. Luminaire can be driven over at low speed. Silicone rubber gasket. Factory-sealed termination chamber with cable gland and 1.5 m of flexible PVC-free cable. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. Removable LED boards for upgrading. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept. 20° tiltable and 355° rotatable. 1-10 V analogue dimming or DALI interface available on request. Luminaire installation blockout and sealable junction box included in supply.
