LUCI

The luminaire is made of cast aluminium, designed as heat sink, with connection cable L 500mm. Fixing springs for ceiling thicknesses of 1-40mm. 4-pole terminal block. Includes ERCO DALI control gear. LED module: high-power LEDs. Lens system made of optical polymer. Anti-glare cone with covered mounting detail: polymer, black. Optical cut-off 30°. Dimming possible via commercially available push-buttons (Push Dim). The luminaire is protected on the room side against splashing water.

Wireless Movable Type smallest and Lightest

Compact Spot Light of Beautiful Light

With its movement function unchanged, and maintaining its high light quality, it is suited for narrow, hard to reach areas or for illuminating display or work spaces.

Illumination scenarios can also be automated over time using the timer.

Communication Distance: About 20m (without any communication obstacles around)

Can be save up to 16 Scenes

W : 179 / H : 221 / φ53 (mm) / 0.8kg

Communication Specification: Bluetooth4.0

Moving Range: Horizontal 0~180°　Vertical -90°～+90°

Inground walk over fitting. Recessing depth 125 mm. IP rating IP 65 IP67. This luminaire contains built-in LED modules. In case of damage or malfunction please contact the manufacturer to receive additional instructions on how to replace and relative spare parts to order. The LED modules cannot be handled in the luminaire by the end user.Surface temperature of glass 40°C (Ta 25°C).

Single emission projectors for outdoor application. The warm white LED light source with a wide flood light distribution is composed of 1 arrayled LEDs with CCT of 3000 K and a CRI 80; the source luminous flux is 770 lm, with a 128.3 lm/W nominal luminous efficacy. The device body is made of die-cast aluminium en ab - 46100 and features a white finish, processed by means of open pore anodizing + powder coating; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP66.
