Based on the experience gained with PROLICHT Vertical Boost Wallwashers, the MAGIQ Hollow Wallwash recessed spotlight was designed as a range extension of the popular MAGIQ product family. With the 8 fully integrated Bartenbach reflectors we are able to finish flush with the ceiling, even with a wallwasher. The interaction of the patented reflectors with the mirror elements makes it possible to use it as a glare-free wallwasher that invisibly integrates into well thought-out architecture.

The Spotify Concave Round series is versatile downlights with high-definition optics and advanced LED technology delivering optimal visual comfort. Available in Dia 76 and 100 mm, trim and trimless versions with tools-free interchangeable optics accessories, it is fully adjustable with vertical tilt 0°-35° inside the ceiling level and rotates 355°.Developed as an ECO design for the circular economy, with its modularity, interchangeable optics and accessories, and tool-free mounting.Application areas: Highend residential and retail projects, hotels, museums, and galleries. The color temperature avaiable 2700k,3000k,3500k and 4000k.

"Copper Free" Aluminium die cast housing in EN AB-44100 with high resistance against corrosion. Stone wash surface treatment prior to painting process. A4 grade Stainless Steel screws with 2,5-3% molybdenum content which increases the resistance against corrosion. Pre treated Silicone Gaskets. Painting Process: 3 Step Process: 1) Surface treatment with BONDERITE. A heavy metal free chemical surface treatment containing ceramic nano particles giving a cohesive, inorganic and highly dense protective coating. 2) PRE POLYMERIZATION a process of introducing an epoxy primer with excellent characteristics to the paint which also offers very high resistance to oxidation due to its Zinc content. 3) POLYMERIZATION a process with the application of polyester powder with high resistance against UV rays and harsh weather conditions. Resistance test protection for Marine applications for 1200h. Mechanical resistance IK 09 Maximum load capacity 1000 Kg. This luminaire contains built-in LED modules. In case of damage or malfunction please contact the manufacturer to receive additional instructions on how to replace and relative spare parts to order. The LED modules cannot be handled in the luminaire by the end user. This product contains a light source of energy efficiency class: E. LED modules are engineered accordingly to the existing regulations of Lumen Maintenance (LM80) and Technical Memorandum (TM21), where uniformity and quality of the light is 70,000 hours referred to L80 B10 Ta 25 ° C (50,000 hours referable to L80 B10 Ta 40°C). Lifespan of the luminaire min. 50,000 hours at 40°C. Performance Ambient temperature Tq 25°C. Operating ambient temperature range is from -20°C to +50°C. Storage temperature range from -20°C to +60°C.

Recessed linear downlight, luminaire body made of aluminium housing with white powder coated trim finish. Reflector available Silver, Black Chrome and White finish. Black finish and honeycomb accessory available upon request.
