CDN LIGHTING

Miniaturised adjustable spotlight with adapter for installation on a 48V Filorail low voltage track. The thermoplastic adapters are designed so they can be installed even in the curved track sections. Die-cast aluminium body with an ideal passive dissipation system to guarantee a long life and effective heat management.

Single emission ceiling lights for indoor application. The warm white LED light source with a flood light distribution is composed of 1 arrayled LEDs. The device body is made of die-cast aluminium en ab - 46100 and features a embossed black ral 9005 finish, processed by means of powder coating. The ingress protection degree is IP20; the total weight is of 0.870 kg. The power supply driver is not provided and is to be ordered separately. The device features protection class III and can be ceiling-mounted, with a 57 mm diameter hole (in plasterboard). Compliant with the EN 60598-1 standard and its specific provisions.

Inground uplight cover ring luminaire made of stainless steel housing and cast stainless steel. Steel grade number 1.4301. Clear safety glass, reflector made of pure anodised aluminium material. 2 mounting holes ø 5mm Distance apart 120mm, 1,8m water-resistant connecting cable 05RN8-F 3G1@ with implemented water stopper and 1.2m PVC cable conduit. BEGA Thermal Switch® Temporary thermal shutdown to protect temperature-sensitive components Safety class I Protection class IP 68 10m, IK10. DIMENSION : (W)115x(H)100x(D)130mm.

Housing: cast aluminium, with connec- tion cable L 850mm. 0°-40° tilt, 360° rotation. Lockable angles of tilt and rotation.
