768C.15

Direct light linear luminaire, designed to use monochrome LED lamps. For ground and wall installations,, the product requires an outer casing (to be purchased separately). The outer casing is not required for installations in panelled walls and ceilings. The body is made of extruded aluminium and includes die-cast aluminium end caps with 50/60 Shore A silicone seals.Fitted with an Opti Beam Lens optical system with a Wall Grazing Wide Flood optic.

Specification

Power
7.6W
Color Temperature
3000K
Light Source Type
LED
Lumen Output
560lm
Finishing
GREY
IP Rating
IP65
Color Rendering
CRI 90
Driver
ON/OFF DRIVER

See more
