IGUZZINI

ADJUSTABLE DOWNLIGHT

INDOOR LIGHTING

P327.01

Round recessed luminaire with contact frame. Adjustable version that tilts by a maximum of 30°. The main swivel body is made of die-cast aluminium with a radiant surface that guarantees optimum heat dissipation. High color rendering index 3,000K LED. Power unit available with a separate code no. Direct current ballasts are available with a separate code no.: ON-OFF / 1-10V dimmable / DALI dimmable

Specification

Power

Color Temperature

3000K

Light Source Type

LED

Lumen Output

656LM

Finishing

WHITE TRIM - WHITE REFLECTOR

IP Rating

IP20

Color Rendering

CRI 90

Driver

1-10V DRIVER

XAL

RECESSED DOWNLIGHT

INDOOR LIGHTING

Rectangular recessed multi-downlight made of die-cast aluminium; installation without tools in mounting set due to patented ball catch system; rectangular installation housing; for trimless installation in plasterboard ceilings; suitable for ceiling thickness of 12.5/15/20/25 mm; equipped with two wide flood round light elements; symmetrical light distribution with precise radiation characteristic, beam angle 72°; high quality reflector with micro-faceted, aluminum-vaporised surface; black reflector; passive cooling of the LEDs through improved heat sink geometry; light colour 3000 K; binning initial MacAdam ≤ 3 SDCM; CRI ≥ 90; min. 90% of luminous flux after 50000 operating hours; energy-efficient high power LEDs with very good colour rendering; degree of protection IP20; PC2; incl. converter, non dimmable; through wiring connection box, 3-pole or 5-pole, available as an accessory; accessories are listed separately; light source not replaceable; control gear replaceable by an authorized professional; clank-free

DELTALIGHT

CEILING LIGHT

INDOOR LIGHTING

Super Oh series of slim black rings floating through space, finished either with integrated powerleds or the more retro-look version with classic light bulbs. With its 25cm or 39cm diameter, the Super-Oh XS (Extra Small) can be considered to be “little one” of the family. This circle of leds is specially designed to guarantee a uniform and perfectly balanced light output, resulting in a very enjoyable diffuse lighting effect. The Super-Oh XS is available either for direct mounting, as a suspension or with a pivot, a flexible ceiling bracket enabling the user to tilt the disc up to 45°, and rotate 360°.

IGUZZINI

SPOTLIGHT

INDOOR LIGHTING

Miniaturised adjustable spotlight for surface mounting with special base. The body is made of painted die-cast aluminium, with a passive dissipation system that ensures optimal thermal management. Rear cap and front ring in thermoplastic material (Mass-Balance). LED source with high colour rendering C.O.B (Chip on board) technology. The joint system allows a 360° rotation and a 90° inclination, offering flexibility in the orientation of the light beam.

LIGHTFORMS

RECESSED LINEAR LIGHT

INDOOR LIGHTING

GlowBeam Recessed is a recessed luminaire that once installed has the appearance of surfacemounted fixture. An acrylic light conveyor “blade” extends down from the ceiling plane to provide ambient illumination. The acrylic blade is available as either fully frosted (OPAQ) or translucent with the end- and bottom-sides frosted (TRANS). The luminaire is specifiable in four lengths ranging from 615-1215 mm.
