Products

RCL

ADJUSTABLE DOWNLIGHT
INDOOR LIGHTING
DRX7 - TUNABLE WHITE

DRX7 LED (25W/50W for light source) recessed luminaire available in narrow, medium and wide beam angles as well as variable beam offerings. Color temperatures offered include 2700K, 3000K and 4000K. . Movement and Dimming is controlled using a handheld remote. Other protocols available include DALI, DMX, 1-10V and RCL Control iPad app. Recording and recall of luminaire position (pan and tilt) with handheld remote controller as standard.

Specification

Power
34W
Color Temperature
2700K - 6500K
Light Source Type
LED
Lumen Output
2800LM
Finishing
BLACK
IP Rating
IP20
Color Rendering
CRI >90
Driver
DIMMABLE DRIVER

See more

LUCI
LED STRIP
INDOOR LIGHTING
Only 5.8 mm thickness with dot-free light emitting surface Custom lengths available in every 25mm increment, up to 1508mm Selectable between both or one side cable feed, open end or connector
RCL
RECESSED DOWNLIGHT
INDOOR LIGHTING

DR7 3000K LED (30W for light source) standard trim recessed luminaire with 17° optic. Manufactured from LM24 aluminium and glass-filled polycarbonate, with a mild-steel mounting ring. Finished in white (RAL 9010). Voltage is 220-240V 50/60HZ. Luminaire has high-performance colour rendering of 90+ CRI. Luminaire can be rotated, with +/- 175° movement through the pan axis and •+/-35° through the tilt axis, at a resolution of less than 1° in either axis. Movement and dimming is controlled using DMX. Recording and recalling of scenes as standard

PUK
FLOODLIGHT
OUTDOOR LIGHTING
Floodlight for outdoor installation on a façade/wall, with 355° swivel base and allowing horizontal adjustment of +90° / -40°. Phospho-chromatised and polyester powder coated die-cast copper-free aluminium base and head, tempered safety glass, moulded silicone gaskets and o-rings, with screws in stainless steel. Swivel joint with graduated scale and mechanical aiming lock. Built-in LED driver, with 12 x CREE “XHP35” LED. IP66 rating.
SPARK
SURFACE TRACKLIGHT
INDOOR LIGHTING

Track Adjustable Spotlight luminaire body made of aluminium housing with white powder coated finish. Reflector finish available White, Silver and Black Chrome. Black finish and honeycomb accessory available upon request.
