UNILAMP

LED source. 316L stainless steel body and bracket, suitable for submersion. Remote power supply 350 mA ON/OFF and dimmable 1-10V or DALI. Must be ordered separately. Serial connection. Equipped with a 5000 mm protruding section of neoprene cable and a kit with crimpable connectors and adhesive heatshrinkable sleeves that guarantee the tightness of the connection. Extraclear transparent glass, IP68,IK05.

LUMINAIRE TYPE:Inground walk over fitting. Recessing depth 245 mm. IP rating IP 67

"Copper Free" Aluminium die cast housing in EN AB-44100 with high resistance against corrosion. Stone wash surface treatment prior to painting process. 2 mm thick front trim in Stainless Steel - Grade AISI 316L with 2,5-3% molybdenum content. A4 grade Stainless Steel screws with 2,5-3% molybdenum content which increases the resistance against corrosion. Mechanical resistance IK 09 Maximum load capacity 1020 Kg

Single emission projectors for indoor application. The warm white LED light source with a wide flood light distribution is composed of 1 powerled LEDs. The device body is made of aluminium 6026 and features a embossed black ral 9005 finish, processed by means of powder coating. The ingress protection degree is IP40; the total weight is of 0.08 kg. The power supply driver is not provided and is to be ordered separately. The total absorbed power is 2 W. The power supply cable is included and features a 1 m length. The device features protection class III and can be wall lights, ceiling or floor-mounted. Compliant with the EN 60598-1 standard and its specific provisions.

Single emission lines for outdoor application. The natural white LED light source with a asymmetric wallwasher light distribution is composed of 120 topled LEDs. Luminaire body is made of PC and features a transparent finish the diffuser is made of PC. The ingress protection degree is IP67. IK08
