LINEALIGHT

Luminaire made of copper, brass and stainless steel. Crystal glass coated 2 fixing holes ø 5.5 mm, 108 x 108 mm spacing, 1 cable entry for mains supply cable up to ø 10,5 mm max. 3 × 1,5@ Connecting terminal 2.5@ Earth conductor connection. LED power supply unit 220-240 V x 0/50-60 Hz. DC 176-280 V. Safety class I. Protection class IP 64. Dust-tight and protection against splash water. Impact strength IK07. Protection against mechanical. impacts < 2 joule, r – Safety mark, c – Conformity mark.

The in-ground uplighter range is designed to fulfill the demands of sophisticated lighting projects. The luminaires combine all crucial product advantages precise light distributions, perfect glare control, adjustable reflectors and shallow recess depth. Uplight 220 and 260 are equipped with the innovative Heat Slide mechanism which allows the optical system to be adjusted and aimed whilst the LED module remains connected to the luminaire housing. Thus efficient heat dissipation and a long lifetime of the LED is achieved. The luminaires are now available with innovative wall washeroptics for uniform illuminaition from thebottom to the top of the facade.

Next-generation recessed lighting fixture "Laser Evo", designed to offer

high optical performance, maximum efficiency, and an integrated design for

various architectural environments.

Recessed mount designed for easy and precise installation in a Ø96 mm

mounting hole.

Frame version (with trim frame).

Fixture with Wall Washer-style front aesthetics for uniform and controlled

vertical surface illumination.

LED color temperature 3000K with high color rendering index.

CRI97.

Version with reflector.

Miniaturized lighting fixture Laser Blade XS Linear optical element with 2 cells (2 LEDs) Recessed lighting fixture with a radiant surface in die-cast zama, complete with springs for installation. Frame version with a perimeter trim. LED Single Chip High Power 3500K LED Color Rendering Index -CRI90- High-definition Opti Beam reflector in metallized thermoplastic material. FLOOD optics. White painted polycarbonate raster. Product does not include a driver; it must be ordered separately.
