LINEALIGHT

RECESSED LINEAR LIGHT

INDOOR LIGHTING

81329N00

Single emission lines for outdoor application. The natural white LED light source with a diffused light distribution is composed of 210 topled LEDs with CCT of 3500 K and a CRI 80; the source luminous flux is 707lm.

The device body is made of uv resistant polycarbonate and features a opaline finish,

Specification

Power

15W

Color Temperature

3500K

Light Source Type

LED

Lumen Output

707LM

Finishing

WHITE

IP Rating

IP67

Color Rendering

CRI 80

Driver

ON/OFF DRIVER

LIGHTFORMS

SURFACE TRACKLIGHT

INDOOR LIGHTING

Lightplane 2.5 is a compact and streamlined luminaire that provides direct, indirect or directindirect illumination from a suspended, wall or surface mounted channel. The fixture is available with several LED lamping options including multiple outputs and CCTs, tunable white and colour-changing RGB+White. A Low UGR option is available with a prismatic lens is also available.

LINEALIGHT

PROJECTOR LIGHT

OUTDOOR LIGHTING

Single emission projectors for outdoor application. The super warm LED light source with a medium flood light distribution is composed of 1 arrayled LEDs with CCT of 2700 K and a CRI 80; the source luminous flux is 2349 lm, with a 130.5 lm/W nominal luminous efficacy. The device body is made of die-cast aluminium en ab - 46100 and features a dark brown finish, processed by means of open pore anodizing + powder coating; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP66, IK10.

LINEALIGHT

WALLWASHER

OUTDOOR LIGHTING

Single emission lines for outdoor application. The warm white LED light source with a diffused light distribution is composed of 90 topled LEDs. The device body is made of uv resistant polycarbonate and features a black finish; the diffuser is made of uv resistant polycarbonate. The ingress protection degree is IP67; the total weight is of 0.40 kg. The power supply driver is not provided and is to be ordered separately. The power supply cable is included and features a 0.25 m length. The device features protection class III and can be wall lights or floormounted. Compliant with the EN 60598-1 standard and its specific provisions.
