ELR

Recessed luminaire that can be installed in walls, ceilings and floors. It is designed to use white monochrome LED lamps. The luminaire is fixed to the outer casing using special locking seals that hold it in place. The unit comes complete with LED circuit and a metallized plastic reflector. The product's wiring system features an A2 stainless steel cable gland. The cable is equipped with an anti-transpiration device (IP68) that consists of a silicone-coated joint located on the power cable. Two types of outer casing are available for installation and both can be ordered separately from the plastic optic assembly. The glass unit, optical assembly and outer casing together guarantee a maximum static load resistance. The maximum surface temperature of the glass is less than 40°. Luminaire protected against polarity inversion.

IP69. IK10+. Stainless steel construction including PCS hardware. Safety glass lens, max. load 5 tonnes. Luminaire can be driven over at low speed. Silicone rubber gasket. Factory-sealed termination chamber with cable gland and 0.5 m of flexible PVC-free cable. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. Removable LED boards for upgrading. CAD-optimised optics for superior illumination and glare control. OLC One LED Concept. 20° tiltable and 355° rotatable. 1-10 V analogue dimming or DALI interface available on request. Luminaire installation blockout and sealable junction box included in supply.

Protection class IP68 – up to 5m water depth. Protection class IP69 - protection against high pressure and high jet water temperatures. Entirely made of stainless steel 316Ti. Round attachment cover, made of stainless steel 316Ti, height 3 mm. POW-LED cold white, warm white, neutral white. POW-LED blue. Multichip POW-LED RGB. Multichip POW-LED RGB-W. Multichip POW-LED Dynamic white. Operating mode: constant current. Rotationally symmetric light distribution. Cable gland M16x1,5. Constant-current power source/RGB controller external. Installation housing made of stainless steel 316Ti with 1.5 m cable protection tube and connection socket (order separately). Supplied with lamp and 3 m of underwater cable.

The Athena Bollard Light is exceptionally durable, thanks to TetraCoat, Unios' four-layer body construction method developed to withstand harsh outdoor conditions. With reduced environmental impact and enhanced visual comfort for occupants, the Athena stands out as an excellent choice for outdoor lighting.
