IGUZZINI

WALLWASHER
INDOOR LIGHTING
LASER_QA70.04

Minimal round recessed luminaire (frameless). Wall Washer fixed version: the optic system is designed to aim the light flow on a vertical surface with no shadow zones and a precise outline. The main body is made of die-cast aluminium with a radiant surface that guarantees optimum heat dissipation. The optic unit includes two shaped metallized thermoplastic reflectors, a PMMA refractor/safety screen and a plastic anti-glare casing available in a range of painted and metallised finishes. Die-cast aluminium structure designed for flush with ceiling installation - a specific adapter with a separate code is available for false ceilings. This is indispensable for installing recessed luminaires. LED lamp with high color rendering index. Power unit available with a separate code no. IP20.

Specification

Power
10W
Color Temperature
3000K
Light Source Type
LED
Lumen Output
607LM
Finishing
BLACK
IP Rating
IP20
Color Rendering
CRI>90
Driver
ON/OFF DRIVER

See more

HELVAR
CONTROL SYSTEM
CONTROL SYSTEM

The Power Supply Module is an ultra compact DIN railmounted unit with connections for a single M-BUSnetwork via screw terminals and a patch lead socket.The Power Supply Module provides up to 800mA,24V DC. Additional Power Supply Modules can beadded if required.

ROLEDS
RECESSED DOWNLIGHT
INDOOR LIGHTING


LIGMAN
WALL LIGHT
INDOOR LIGHTING
Luminaire made of die-cast aluminium end-caps and extruded aluminium profile with powder coating. Single cable entry, stainless steel fasteners in grade 316. PMMA diffuser with Opal (UGR <19) and micro prismatic (UGR <13) options for better glare control. Up and down light distribution options. Passive thermal management, integral control gear. Wireless control available through Bluetooth connection. Daylight and occupancy sensor options. Emergency module (1 or 3 hours) is available upon request with 3 options (BASIC, SELF-TEST, PRODALI). IP20.
WE-EF
SURFACE MOUNTED LIGHT
OUTDOOR LIGHTING
Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Safety glass lens. Silicone CCG® Controlled Compression Gasket. Luminaire is factory-sealed and does not need to be opened during installation. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept. Optional 2200 K version up to max. 1050mA available. To be specified at time of ordering. Luminaire can be mounted for up or down lighting.
