PALCO INOUT_EH93

Spotlight designed to use LED lamps and a Flood optic. The optical assembly and base is made of EN1706AC 46100LF aluminium alloy and subjected to a multi-step, pre-treatment process, in which the main phases are degreasing, fluorozirconation (a protective surface film) and sealing (with a nano-structured silane layer). The following painting stage consists of a primer and a liquid acrylic paint, cured at 150°C, with a high level of weather and UV ray resistance. 5 mm thick tempered sodium-calcium closing glass. Double adjustability allows a 360° rotation about the vertical axis and 90° tilting relative to the horizontal plane. IP66 , IK07.

Specification

Power
10.9W
Color Temperature
2700K
Light Source Type
LED
Lumen Output
665LM
Finishing
BLACK
IP Rating
IP66
Color Rendering
CRI>80
Driver
DALI Driver

See more

LINEALIGHT
INGROUND UPLIGHT
OUTDOOR LIGHTING
Single emission uplights for outdoor application. The warm white LED light source is composed of 1 arrayled LEDs. The luminaire body is made of aisi 316l steel and features a steel finish; the diffuser is made of extra clear glass with a silk-screening treatment. The ingress protection degree is IP68.
SIMES
WALL LIGHT
OUTDOOR LIGHTING

MATERIAL CHARACTERISTICS

Aluminium die cast housing in EN AB-47100 (low copper content) with high resistance against corrosion. Stone wash surface treatment prior to painting process. A4 grade Stainless Steel screws with 2,5-3% molybdenum content which increases the resistance against corrosion. Silicone gaskets. Painting Process: 3 Step Process

LIGHTING PERFORMANCE

Reflector in polymers covered with 99.98% pure aluminium. Luminaires come with toughened glass lenses already installed and are aff

APEX
LED STRIP
INDOOR LIGHTING

TUNABLE LED Strip 120 degree beam, 192 leds/m. 62.5mm cut length 24V voltage. Tunable color 3000K - 6000K. Suitable for Indoor and Outdoor application. IP20 / 65 / 67. DIMENSION : L1000mm x W10 mm.

ERCO
ADJUSTABLE DOWNLIGHT
INDOOR LIGHTING

The black powder-coated cast aluminum housing doubles as a heat sink, with a 0°-30° tilt and 850mm connection cable. It features a 360° rotatable fixing ring, expanding spring mounting, and an ERCO Casambi control gear. The high-power LED module includes a color mixer, collimating lens, and Darklight optical polymer lens with a 40° cut-off. Controlled via the Casambi app (BLE). Approved for emergency lighting (IEC/EN 60598-2-22). Protection Class II. Weight: 0.70kg.
