XAL

SURFACE MOUNTED DOWNLIGHT
INDOOR LIGHTING
SASSO 100 ADJ_048-34010111W 002-90766

Cylindrical semi-recessed spotlight made of aluminium; surface black/black (housing/light inset); 360° rotatable and 20° tiltable; luminaire housing can be attached to mounting plate without tools by interlock; passive cooling of the LEDs through improved heat sink geometry; with COB (Chip on Board) technology for maximum efficiency; no appearance of multiple shadows

Specification

Power
17.9W
Color Temperature
3000K
Light Source Type
LED
Lumen Output
1750LM
Finishing
BLACK TRIM / BLACK REFLECTOR
IP Rating
IP20
Color Rendering
CRI 90
Driver
ON/OFF DRIVER

See more
