SPARK

Traxon linear GO Mini is a DC line powered exterior luminaire used to distinguish facades, walls and architectural landmarks with a powerful, even color wash effect. Linear GO high-value design features efficient electrical and optical systems, making it ideal for budget-conscious projects. IP66 and IK06

DIMENSION : 1200*30*77.1MM

wall mounted for outdoor applications, single beam; surface mounted (wall); Power consumption: 3W; Power supply: 24Vdc; Lumen output at source: 147 lm (3000K, CRI >90); Delivered lumen output: 128 lm (3000K, 22°, CRI >90); 1 power LED, 1/4 ANSI BIN, 50 000h L90 B10 (Ta 25°C); LED colour: 2700K; Optics: 22°: optical system consisting of a high-efficiency TIR lens

Round recessed spotlight in die-cast aluminium; 1 lamp; surface jet black; installation without tools in mounting set due to patented ball catch system; round installation housing; with trim jet black; suitable for ceiling thickness of 2-25 mm; passive cooling of the LEDs through improved heat sink geometry; with COB (Chip on Board) technology for maximum efficiency; no appearance of multiple shadows; light colour 2700 K; ≤ 2 SDCM (initial MacAdam); CRI ≥ 90; min. 80% of luminous flux after 5000

Rectangular surface mounted multi-downlight made of aluminium; luminaire housing can be attached to mounting plate without tools by interlock; converter integrated into luminaire housing; surface jet black powder coated; equipped with six medium round light elements; symmetrical light distribution with precise radiation characteristic, beam angle 33°; high quality reflector with micro-faceted, aluminum-vaporised surface; Reflector black; UGR ≤ 10; passive cooling of the LEDs through improved hea
