SPARK

ADJUSTABLE DOWNLIGHT

INDOOR LIGHTING

SPK2621-20W-55D

Recessed adjustable square downlight, luminaire body made of aluminium housing with white powder coated finish. Black finish and Honeycomb accessory available upon request.

Specification

Power

20W

Color Temperature

3000K

Light Source Type

LED

Lumen Output

1610LM

Finishing

WHITE

IP Rating

IP20

Color Rendering

CRI 90

Driver

ON/OFF DRIVER

LINEALIGHT

WALLWASHER

OUTDOOR LIGHTING

Single emission lines for outdoor application. The warm white LED light source with a elliptic light distribution is composed of 18 powerled LEDs. The device body is made of aluminium 6060 and features a anodised aluminum finish, processed by means of 20 µm anodizing; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP67; the total weight is of 11 kg. The total absorbed power is 89 W. The power supply cable is included and features a 0.17 m length. The device features protection class I and can be floor-mounted with an outer casing, code 99772 (for concrete or masonry). Compliant with the EN 60598-1 standard and its specific provisions.

XAL

LINEAR DOWNLIGHT

INDOOR LIGHTING

Rectangular recessed multi-downlight made of die-cast aluminium; installation without tools in mounting set due to patented ball catch system; rectangular installation housing; for trimless installation in plasterboard ceilings; suitable for ceiling thickness of 12.5/15/20/25 mm; equipped with four medium round light elements; symmetrical light distribution with precise radiation characteristic, high quality reflector with micro-faceted.

HELVAR

CONTROL SYSTEM

The RS232 Interface is compatible with Evolution control systems which both use the standard mode lighting M-BUS network. The small form factor and multi-device connectivity makes the MBUS-INT-232 a flexible addition to any system. The RS232 Interface extends the integration capabilities of the Mode Lighting control system by adding extra RS232 connections. The interface is bi-directional allowing the systems to send commands to external devices and receive commands from integration control sys
