SPARK

Housing made of corrosion‑resistant die‑cast aluminum AlSi12, polyester powder coated by high‑quality and UV‑stabilized coating process, Colour: black ral 7021, all exterior parts are stainless steel, tempered safety glass, anti‑reflective coating from 1 side, dark screenprint, silicon gasket, closure with 4 stainless steel screws, for installation on poles Ø 60 ‑ 100 mm, tiltable base made of powder coated aluminum, 2 drilled holes Ø 9 mm, spacing 95 mm, 1 centre hole Ø 13.5 mm, tilt range: 90°, 360° adjustable, cable gland: M20, connecting terminal: 3 pole, precise PMMA optics, integral driver (AC/DC), CRI > 80, max 2 SDCM, service life L90/B10 > 50.000 h, Beam angle (fwhm): 44°, luminous flux: 1460 lm, wattage: 23 W, delivered lumens 63 lm/W, protection type IP65, protection class I, impact resistance IK08, windage area 0,016 m², dimensions (L×H×W): 126 × 97 × 126 mm, weight 1.8 kg. The modular luminaire design makes the replacement of components possible. The product meets the demands of the applicable EU guidelines and product safety regulations and bears the CE mark. Customized solutions and modifications are possible: Special ral, db or ncs colours as polyester powder coat, luminaires in 2700 K and other colour temperatures and versions for high ambient temperature.

The Laser Blade is a compact, high-efficiency downlight designed for visual comfort and architectural precision. With miniaturized optics and a sleek 281 mm profile, it delivers 1840 lumens at 93.9 lm/W, all while maintaining a low glare (LOR 85) and CRI of 90. Its pinpoint beam angle of 50° provides seamless circular light, ideal for refined, invisible lighting effects. Weighing just 0.6 kg, it combines advanced technology, flexible design, and award-winning innovation in a discreet IP20-rated

LED source included. Electric remote 24V dc ON/OFF power supply to be ordered separately. Wall fixing bracket included. The luminaire is equipped with a protruding, neoprene, 250 mm cable and a wiring kit with crimp connectors and adhesive heat shrink tubing guaranteeing the water tightness of the connection. Extra clear transparent glass

Round surface luminaries with body and satin opal diffuser in injection molded polycarbonate inclusive of durable silicone gasket. External frame in cast aluminium with countersunk screws. Simple to install with 2 cable entries to facilitate through wiring and easy click system removable diffuser.
