LINEALIGHT

RECESSED DOWNLIGHT
INDOOR LIGHTING
64509W45

Single emission downlights for indoor application. The warm white LED light source with a medium wide flood light distribution is composed of 3 powerled LEDs with CCT of 3000 K and a CRI 80; the source luminous flux is 1470 lm, with a 122.5 lm/W nominal luminous efficacy. The device body is made of iron and features a white + black finish, processed by means of powder coating; the diffuser is made of pet. The ingress protection degree is IP20; the total weight is of 0.36 kg. The power supply driver is not provided and is to be ordered separately. The total absorbed power is 12 W. The power supply cable is included and features a 0.170 m length. The device features protection class III and can be ceiling-mounted, with a 113 x 42 mm hole (in plasterboard). Compliant with the EN 60598-1 standard and its specific provisions.

Specification

Power
12W
Color Temperature
3000K
Light Source Type
LED
Lumen Output
832LM
Finishing
BLACK
IP Rating
IP20
Color Rendering
CRI 80
Driver
ON/OFF DRIVER

See more

LINEALIGHT
WALLWASHER
OUTDOOR LIGHTING
Single emission lines for outdoor application. The warm white LED light source with a medium flood light distribution is composed of 12 powerled LEDs. The device body is made of aluminium 6060 and features a anodised aluminum finish, processed by means of 20 µm anodizing; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP68; the total weight is of 2.010 kg. The power supply cable is included and features a 0.250 m length. The device features protection class II and can be floor-mounted with an outer casing, code 99764 (for concrete or masonry). Compliant with the EN 60598-1 standard and its specific provisions.
LUCE & LIGHT
UNDERWATER LIGHT
OUTDOOR LIGHTING


VIBIA
WALL LIGHT
OUTDOOR LIGHTING

ORIGAMI blends light functionality with an opportunity for artistic creation. With just two pieces, designers can create infinite compositions. With a single connection point between the pieces and simple surface mounting installation, you can make as many configurations as you desire. ORIGAMI lighting is rated for both outdoor IP65 and indoor settings which you can construct to climb a wall or faade like ivy. The light source is LED, guaranteeing high-efficiency energy consumption.

XAL
ADJUSTABLE DOWNLIGHT
INDOOR LIGHTING

Round recessed adjustable spotlight; 360° rotatable and 30° tiltable;(UGR ≤ 13); light colour 3000 K; ≤ 3 SDCM (initial MacAdam); CRI ≥ 90; min. energy efficient LEDs with high CRI; incl. high quality lens system; precise radiation characteristic with 25° beam; Rg: 98 | Rf: 91 | R{1-15}: 89,MR 0.6 | MDER 0.55, degree of protection from below IP40 (from above IP20); PC2; 220-240 V; incl. converter, non dimmable. (Product code 048-2820517M 048-2896317 002-90752)
